Запчасти Case IH 1822 (9E-16) - ENGINE AND RADIATOR SHIELDS (12) - CHASSIS

1

1260025C1

SUPPORT

- shield outer

2шт.

2

1260123C1

CHANNEL

- hinge support

2шт.

3

1260011C1

SUPPORT

ASSEMBLY - rear

1шт.

4

215720C1

HINGE

- shield

2шт.

5

1345136C1

BRACKET

- screen support left (Replaces 1262614C4)

3шт.

6

1270399C2

SHIELD

ASSEMBLY - center front deck

1шт.

7

1278003C2

GUARD

SHIELD ASSEMBLY - front deck

2шт.

8

1278000C1

GUARD

SHIELD ASSEMBLY - center rear deck

1шт.

9

1278124C1

HANDLE

- retractable (If equipped)

1шт.

10

1278009C5

SUPPORT

- shield outer front, left

1шт.

14

1278010C5

SUPPORT

- shield outer front, right

1шт.

15

1269999C1

SUPPORT

- hood panel

2шт.

17

1262776C3

GUARD

SHIELD ASSEMBLY - lower

1шт.

18

1262762C3

GUARD

SHIELD - upper

1шт.

19

1262757C3

GUARD

SHIELD - center, left

1шт.

20

1262758C2

GUARD

SHIELD - center right

1шт.

23

1262761C3

GUARD

SHIELD - lower duct

1шт.

24

NSS

NOT SOLD SEPARAT

SEAL - foam, 7-1/2 inch (Order 87084C1, Serial Range: cut-length)

2шт.

25

1264566C1

SEAL,1219mm L

SEAL - foam, 10-5/16 inch (Order 1264576C1, Serial Range: cut-length)

2шт.

26

1270178C1

SUPPORT

ASSEMBLY - center basket

1шт.

27

1278713C1

SUPPORT

ASSEMBLY - basket

1шт.

28

NSS

NOT SOLD SEPARAT

SEAL - foam, 6-5/16 inch (Order 87084C1, Serial Range: cut-length)

2шт.

29

NSS

NOT SOLD SEPARAT

SEAL - foam, 13-13/16 inch (Order 87084C1, Serial Range: cut-length)

2шт.

30

NSS

NOT SOLD SEPARAT

SEAL - foam, 37-1/2 inch (Order 87084C1, Serial Range: cut-length)

2шт.

31

NSS

NOT SOLD SEPARAT

SEAL - foam, 65 inch (Order 195917C1, Serial Range: cut-length)

2шт.

32

87076C1

SUPPORT

ASSEMBLY - tube

1шт.

33

86952C1

CLIP,ELECTRICAL

CLIP - screen support

4шт.

34

NSS

NOT SOLD SEPARAT

STRIP - rubber, 4 inch (Order 87281C1, Serial Range: cut-length)

1шт.

35

NSS

NOT SOLD SEPARAT

STRIP - rubber, 12 inch (Order 87281C1, Serial Range: cut-length)

1шт.

40

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

Hex, 5/16"-18 x 3/4", G5, Full Thd

123шт.

41

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

143шт.

42

9635082

NUT,5/16" - 18, Gr 5

166шт.

43

495-11041

WASHER,0.406" ID x 0.812" OD x 0.065" W

- flat, 11/32 x 13/32 x 13/16 3/64 inch

8шт.

44

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

- hex, 5/16 NC x 3/4 inch

3шт.

45

28588R1

WASHER

- flat, 11/32 x 11/16 x 3/64 inch

70шт.

46

113-421

BOLT,Hex, 1/2" - 13 x 2", Gr 5

12шт.

47

192-23

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

12шт.

48

129-105

NUT,Hex, 1/2" - 13, Gr 5

12шт.

49

199953C1

SELF-TAP SCREW,HWH, 5/16" - 18 x 13/16"

SCREW, SELF TAP, Hex Wash Hd, 5/16"-18 x 13/16"

5шт.

53

113-111

BOLT,Hex, 5/16" - 18 x 2-1/2", Gr 5

4шт.

54

113-104

BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5

2шт.

187-1521

SELF-TAP SCREW,3/8" - 16 x 5/8"

BOLT - hex tapping, 3/8 NC x 3/4 inch

5шт.
