Запчасти Case IH 1800 (9E-18) - ENGINE AND RADIATOR SHIELDS, REAR ACCESS DOOR AND SUPPORTS (12) - CHASSIS

1

1270178C1

SUPPORT

- center basket

1шт.

2

1260025C4

SUPPORT

- shield, outer (Replaces support 1260025C3 )

2шт.

3

1262758C2

GUARD

SHIELD - center, right-hand

1шт.

4

1262762C3

GUARD

SHIELD - upper

1шт.

5

1262761C3

GUARD

SHIELD - lower duct

1шт.

6

1278124C1

HANDLE

- retractable

1шт.

7

1262757C3

GUARD

SHIELD - center, left-hand

1шт.

8

NSS

NOT SOLD SEPARAT

SEAL - foam, 13-13/16 inch (351 mm) long, cut from bulk seal 87084C1 below

6шт.

9

NSS

NOT SOLD SEPARAT

SEAL - foam, 6-5/16 inch (160 mm) long, cut from bulk seal 87084C1 below

2шт.

10

1260011C1

SUPPORT

- rear

1шт.

11

NSS

NOT SOLD SEPARAT

SEAL - foam, 10-5/16 inch (262 mm) long, cut from bulk seal 1264566C1 below

4шт.

15

1278003C2

GUARD

SHIELD - front deck

1шт.

17

1278000C1

GUARD

SHIELD - center rear deck

1шт.

20

1269999C1

SUPPORT

- hood sheet

1шт.

22

1260123C2

CHANNEL

CHANNEL - hinge support

2шт.

23

1278713C1

SUPPORT

- front and rear

2шт.

24

87076C2

SUPPORT

- tube (Replaces support 87076C1 )

4шт.

25

86952C1

CLIP,ELECTRICAL

CLIP - screen support

4шт.

27

NSS

NOT SOLD SEPARAT

SEAL - foam, 37 inch (940 mm) long, cut from bulk seal 87084C1 below

4шт.

28

NSS

NOT SOLD SEPARAT

SEAL - foam, 65 inch (1651 mm) long, cut from bulk seal 195917C1 below

4шт.

29

413-524

BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5

- hex, 5/16 NC x 1-1/2 inch

1шт.

30

495-11034

WASHER,5/16", SAE

5/16" SAE (flat, 11/32 x 11/16 x 1/16")

1шт.

31

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

32

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

1шт.

33

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

- hex, 5/16 NC x 3/4 inch

15шт.

36

215720C1

HINGE

- shield

2шт.

37

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

- hex, 5/16 NC x 3/4 inch

8шт.

38

495-11034

WASHER,5/16", SAE

5/16" SAE (flat, 11/32 x 11/16 x 1/16")

16шт.

39

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

8шт.

40

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

8шт.

41

1262776C3

GUARD

SHIELD - lower

1шт.

42

413-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

- hex, 5/16 NC x 1 inch

1шт.

43

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

44

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

1шт.

45

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

- hex, 5/16 NC x 3/4 inch

1шт.

46

495-11041

WASHER,0.406" ID x 0.812" OD x 0.065" W

(Flat, 13/32 x 13/16 x 1/16") 3/8", SAE

8шт.

47

425-106

NUT,3/8"-16, Cl 5

25шт.

48

495-11034

WASHER,5/16", SAE

5/16" SAE (flat, 11/32 x 11/16 x 1/16")

1шт.

49

413-832

BOLT,Hex, 1/2" - 13 x 2", Gr 5

12шт.

50

495-11053

WASHER,1/2", SAE

(17/32" x 1-1/16" x 3/32") 1/2", SAE

12шт.

51

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, 1/2"

12шт.

52

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex 1/2"-13, G5

12шт.

53

413-536

BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5

- hex, 5/16 NC x 2-1/4 inch

4шт.

54

413-524

BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5

- hex, 5/16 NC x 1-1/2 inch

1шт.

87084C1

SEAL

- bulk, foam, adhesive-backed, 600 inch (15240 mm) long

1шт.

1264566C1

SEAL,1219mm L

SEAL - bulk, foam, adhesive-backed, 48 inch (1219 mm) long

1шт.

195917C1

GASKET

SEAL - bulk, foam, adhesive-backed, 600 inch (15240 mm) long

1шт.
