Запчасти Case IH 1400 (2-18) - ENGINE MOUNTING (01) - ENGINE

REF

INSTRUCTION

ENGINE ASSEMBLY - D-358 Diesel Engine, see the Diesel Engines parts catalog 7-1760

1шт.

1

131492C2

SUPPORT

- filter base

1шт.

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

- hex, 5/16 NC x 3/4 inch (Replaces bolt 179816)

1шт.

2

567987R1

SPACER,10.3mm ID x 15.88mm OD x 17.5mm L

- filter support

1шт.

413-624

BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5

- hex, 3/8 NC x 1-1/2 inch (Replaces bolt 179843)

1шт.

3

A152821

HEAD

BASE - coolant filter (Replaces base 427446C1)

1шт.

413-524

BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5

- hex, 5/16 NC x 1-1/2 inch (Replaces bolt 179822)

4шт.

4

121894C1

FAUCET,3/8" - 18 NPTF x 5/8" - 24

VALVE - shut-off

2шт.

5

217-44

REDUCER,1/2" - 14 NPT x 3/8" - 18 NPT

(Replaces reducers 120322 and 144039) 1/2"-14 NPTF x 3/8"-18 Fem NPTF

2шт.

6

222-28

HYD CONNECTOR,5/8"-24 x 3/8" NPTF W/Nut

ADAPTER - engine (Replaces adapter 333773R1)

2шт.

7

222-48

ELBOW,90º, 13/16"-18 Fem x 3/8"-18 NPTF

- 90 degree, compression, 3/8 tube OD x 3/8 inch PT (Replaces elbow 606618C1)

1шт.

8

146455C1

TUBE

- inlet, 24 inch (610 mm) long, cut from bulk hose 995063R1

1шт.

222-104

SLEEVE,3/8" Tube

- tube, 3/8 inch OD

2шт.

222-114

NUT,5/8"-24

NUT - hex, 3/8 inch OD x 5/8 inch

2шт.

9

131485C1

TUBE

- outlet, 14 inch (356 mm) long, cut from bulk hose 995063R1 below

1шт.

222-104

SLEEVE,3/8" Tube

- tube, 3/8 inch OD

2шт.

222-114

NUT,5/8"-24

NUT - hex, 3/8 inch OD x 5/8 inch

2шт.

10

A77544

FILTER

ELEMENT - filter (Replaces element 690171C1)

1шт.

11

217-1063

TEE,3/8" - 18 Female x 3/8" - 18 Male Run

- pipe, 3/8 inch, if used

1шт.

11

444150

TEE,3/8"-18 NPTF Fem x 3/8"-18 NPTF Male Run

- pipe, 3/8 inch, if used

1шт.

12

217-436

PLUG,Hex Soc, 3/8" - 18 NPTF

- hex socket, 3/8 inch PT (Replaces plug 20972R1)

1шт.

12

20958R1

PLUG,Sq Hd, 3/8"-18 NPTF

- pipe, 3/8 inch, no longer used, order plug 217-436

1шт.

995063R1

TUBE

HOSE - bulk, 50 foot (15240 mm) roll

1шт.
