Артикул
Название
Примечание
Количество
87423876
STAND
Assy, Left Hand, Inc. 1 - 19
1шт.
87423878
STAND
Assy, Right Hand, Inc. 1B - 19
1шт.
1
1982682C1
SUPPORT
Left Hand
1шт.
1b
1982683C1
SUPPORT
Right Hand (Not Shown)
1шт.
2
261-84516
SELF-TAP SCREW,Cross Pan Hd, #10 x 1"
3шт.
3
492-11010
LOCK WASHER,#10
3шт.
4
1349998C1
CUP
Water Distributor
1шт.
5
1982416C1
PLATE
1шт.
6
1338720C2
PAD
18шт.
6a
NSS
NOT SOLD SEPARAT
SUPPORT, Moistener Pad
1шт.
7
87421999
HOLDER
Moistener Support, Inc. 6 (1), 6A (1)
18шт.
8
310-1518
BOLT,Hex, 5/16" - 18 x 1-1/8" , Gr 8
18шт.
9
496-21034
WASHER,11/32" x 11/16" x 0.89", HDN
18шт.
12
1329244C1
SHIELD
1шт.
13
413-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
3шт.
15
425-105
NUT,5/16"-18, G5
3шт.
16
669838R1
SPRING CLIP
1/4
36шт.
18
109261A1
TUBE,4.06 mm ID, 6.35 mm OD, 102 mm Length
102 mm (4"), No. 1, Cut From 670199R1
1шт.
18
670201R1
TUBE,0.25" OD, 5.6" Length
152 mm (6"), No. 2, Cut From 670199R1
1шт.
18
670202R1
TUBE,0.25" OD, 7.4" Length
178 mm (7"), No. 3, Cut From 670199R1
1шт.
18
670203R1
TUBE,0.25" OD, 9.1" Length
229 mm (9"), No. 4, Cut From 670199R1
1шт.
18
670204R1
TUBE,0.25" OD, 11" Length
279 mm (11"), No. 5, Cut From 670199R1
1шт.
18
670205R1
TUBE,0.25" OD, 12.9" Length
330 mm (13"), No. 6, Cut From 670199R1
1шт.
18
670206R1
TUBE,0.25" OD, 14" Length
356 mm (14"), No. 7, Cut From 670199R1
1шт.
18
670207R1
TUBE,0.25" OD, 15.6" Length
406 mm (16"), No. 8, Cut From 670199R1
1шт.
18
670208R1
TUBE,0.25" OD, 17.4" Length
432 mm (17"), No. 9, Cut From 670199R1
1шт.
18
670209R1
TUBE,0.25" OD, 19.1" Length
483 mm (19"), No. 10, Cut From 670199R1
1шт.
18
670210R1
TUBE,0.25" OD, 20.9" Length
533 mm (21"), No. 11, Cut From 670199R1
1шт.
18
670211R1
TUBE,0.25" OD, 22.6" Length
584 mm (23"), No. 12, Cut From 670199R1
1шт.
18
670212R1
TUBE,0.25" OD, 24.4" Length
610 mm (24"), No. 13, Cut From 670199R1
1шт.
18
670213R1
TUBE,0.25" OD, 26.2" Length
660 mm (26"), No. 14, Cut From 670199R1
1шт.
18
672476R1
TUBE,0.25" OD, 28.4" Length
711 mm (28"), No. 15, Cut From 670199R1
1шт.
18
672477R1
TUBE,0.25" OD, 30.2" Length
762 mm (30"), No. 16, Cut From 670199R1
1шт.
18
672478R1
TUBE,0.25" OD, 32" Length
813 mm (32"), No. 17, Cut From 670199R1
1шт.
18
672479R1
TUBE,0.25" OD, 32.9" Length
838 mm (33"), No. 18, Cut From 670199R1
1шт.
19
291207C1
CLAMP
15"
2шт.
23
1982745C2
ADJUSTING PLATE
Front
1шт.
24
1982747C2
ADJUSTING PLATE
Rear
1шт.
25
413-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
4шт.
27
495-11034
WASHER,5/16", SAE
4шт.
28
1338549C1
COVER
Water Distribution
2шт.
29
413-820
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
2шт.
30
80679
LOCK WASHER,1/20.507 CST ZND
2шт.
31
496-41053
WASHER,13.49mm ID x 31.75mm OD x 5.05mm Thk
2шт.
36
411-636
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2 1/4", Gr 2
2шт.
37
425-146
JAM NUT,3/8" - 16, Gr 5
4шт.
38
87409736
BRACKET
Left Hand, Lower Mounting
1шт.
38a
87409737
BRACKET
Right Hand, Lower Mounting (Not Shown)
1шт.
39
87409742
ANGLE
Left Hand, Lower Mounting
1шт.
39a
87409743
ANGLE
Right Hand, Lower Mounting (Not Shown)
1шт.
40
409-7616
BOLT,Hex Flg, 3/8" - 16 x 1", Spcl
4шт.
41
495-81135
WASHER,10.31mm ID x 25.4mm OD x 3.4mm Thk
6шт.
42
231-5146
FLANGE NUT,3/8"-16
6шт.
43
409-7820
BOLT,Hex Flg, 1/2" - 13 x 1 1/4", Spcl
2шт.
44
409-7620
BOLT,Hex Flg, 3/8" - 16 x 1 1/4", Spcl
2шт.
45
495-11041
WASHER,0.406" ID x 0.812" OD x 0.065" W
4шт.
46
425-106
NUT,3/8"-16, Cl 5
2шт.
Выбрано товаров: 59
