Запчасти Case IH 625 (35.910.09[01]) - HYDRAULIC VALVE - MECHANICAL HEIGHT CONTROL, PACKAGER TILT, STANDARD COTTON CONTROL SYSTEM, MODEL YEAR 2008 AND PRIOR (35) - HYDRAULIC SYSTEMS

1

REF

INSTRUCTION

VALVE, Chassis

1шт.

2

87395071

HYD TUBE,.625" OD

Steering Return

1шт.

3

87395072

HYD TUBE,15.88 mm OD x 980 mm L

Tilt Raise

1шт.

4

87395073

HYD TUBE,12.70 mm OD x 1000 mm L

Tilt Lower

1шт.

5

1546026C1

CLAMP

3шт.

6

87312610

TUBE,0.375" OD

Steering Pressure

1шт.

7

1546024C1

CLAMP

7шт.

8

87312619

TUBE,0.50" OD

Left Hand Drum Lift Auto

1шт.

9

1546025C1

CLAMP

3шт.

10

87312703

TUBE,0.50" OD

Left Hand Drum Lift Manual

1шт.

11

87312743

TUBE,0.50" OD

Drum Lift Auto Right Hand

1шт.

12

87312754

TUBE,0.50" OD

Drum Lift Manual Right Hand

1шт.

13

87312783

TUBE,0.375" OD

Drum Service Harvest Left Hand

1шт.

14

87448913

SUPPORT ASSY.

1шт.

15

87310985

TUBE,0.375" OD

Drum Service Right Hand

1шт.

16

87313677

TUBE,0.375" OD

Drum Service Harvest Right Hand

1шт.

17

87311931

TUBE,0.375" OD

Drum Service Left Hand

1шт.

18

87314113

TUBE,0.25" OD

Sense to Steering

1шт.

19

93306C2

FILTER

Inline

1шт.

20

1347127C1

PLATE

10шт.

21

495-11034

WASHER,5/16", SAE

7шт.

22

413-544

BOLT,Hex, 5/16" - 18 x 2-3/4", Gr 5

2шт.

23

413-552

BOLT,Hex, 5/16" - 18 x 3-1/4", Gr 5

1шт.

24

413-522

BOLT,Hex, 5/16" - 18 x 1-3/8", Gr 5

3шт.

25

413-532

BOLT,Hex, 5/16" - 18 x 2", Gr 5

2шт.

26

163489C1

STRIP

4шт.

27

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

3шт.

28

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

29

238-6011

O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

1шт.

30

238-6012

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

5шт.

31

238-6014

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

1шт.

32

238-6016

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

1шт.

33

409-7620

BOLT,Hex Flg, 3/8" - 16 x 1 1/4", Spcl

5шт.

34

231-5146

FLANGE NUT,3/8"-16

5шт.

35

201-104

HYD CONNECTOR,1-3/16" - 12 Male ORFS x 1-1/16" - 12 Male ORB

1шт.

36

413-540

BOLT,Hex, 5/16" - 18 x 2-1/2", Gr 5

1шт.

37

495-21038

WASHER,5/16"

1шт.

38

NSS

NOT SOLD SEPARAT

CLAMP

1шт.

39

413-560

BOLT,Hex, 5/16" - 18 x 3-3/4", Gr 5

1шт.

40

87000141

CLAMP

1шт.

41

413-564

BOLT,Hex, 5/16" - 18 x 4", Gr 5

1шт.

42

201-900

CAP,11/16" - 16 ORFS

1шт.

43

201-917

CAP,9/16"-18 ORFS

1шт.
