Запчасти Case IH 625 (88.074.01) - 6RN TO 6RW CONVERSION KIT (88) - ACCESSORIES

Схема запчастей Case IH 625 - (88.074.01) - 6RN TO 6RW CONVERSION KIT (88) - ACCESSORIES
home

Артикул

Название

Примечание

Количество

1

87681144

SERVICE KIT

6RN to 6RW Conversion

1шт.

2

87431913

OUTLET

Front Wide Row

1шт.

3

280641A1

CHANNEL

Out Support

1шт.

4

281769A2

EXTENSION ASSY.

Front Std

1шт.

5

377156A1

ADAPTER

2шт.

6

87448384

OUTLET

Rear Wide Row

1шт.

7

283755A3

EXTENSION

2 Rear, 4 Row Wide

1шт.

8

87408862

EXTENSION

Rear Drum #1

2шт.

9

324164A1

NOZZLE

Wide Outlet Short

1шт.

10

1990497C1

HOUSING

Wide Outlet Short

2шт.

11

1988707C2

GUARD

#3 Front

2шт.

12

1988717C1

SUPPORT

Outlet Mounting

1шт.

13

1546257C1

SUPPORT

Outlet Support Front

1шт.

14

1988802C2

GUARD

Front

1шт.

15

375413A1

CAP

1шт.

16

1546255C3

ANGLE BAR

Outlet Support Front

2шт.

17

1988622C3

GUARD

1шт.

18

84540428

EXTENSION

4 Row 6RW, 3 Row 4RW

1шт.

19

1988712C2

EXTENSION

#3 Front 4 Row

1шт.

20

1546258C1

ANGLE BAR

Outlet Support Front

1шт.

21

1546259C1

SUPPORT

Outlet Support Front

3шт.

22

231-4116

NUT,3/8"-16, GB

50шт.

23

145458

SERRATED NUT,5/16"-18 GR 5 ZND

4шт.

24

409-758

BOLT,Hex Flg, 5/16" - 18 x 1/2", Spcl

9шт.

25

434-58

CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1/2", Gr 5

29шт.

26

477-73108

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"

8шт.

27

477-73112

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"

1шт.

28

87451332

HOOD

1шт.

29

233321A2

PIN,7.94mm OD x 366.5mm L

2шт.

30

136-159

HAIR PIN COTTER,Int, 3/16 x .080"

1шт.

31

87430739

CHUTE ASSY.

Upper Double Outer

2шт.

32

413-432

BOLT,Hex, 1/4" - 20 x 2", Gr 5

2шт.

33

230-4114

NUT,1/4"-20, GA

1шт.

34

417731A1

CHUTE ASSY.

Female

1шт.

35

124483A1

CHUTE ASSY.

Female Outer, 6 Row, 6RN

1шт.

36

417746A1

CHUTE ASSY.

Male

1шт.

37

417748A1

CHUTE ASSY.

Male, 1F, 5R, 6R - 6RN

1шт.

38

87385970

TUBE ASSY.

Side Pipe

1шт.

39

413-532

BOLT,Hex, 5/16" - 18 x 2", Gr 5

1шт.

40

231-4115

NUT,5/16"-18, GB

2шт.

41

248330A1

TUBE,124.6 mm OD, 792 mm Length

2шт.

42

650988C1

CLAMP,130mm

2шт.

43

413-628

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

2шт.

44

495-21044

WASHER,3/8"

2шт.

45

131-822

NUT,3/8"-16

2шт.

46

1984190C1

AIR HOSE

2шт.

47

284896A1

HOSE PROTECTION

4шт.

48

214-3188

HOSE CLAMP,4-3/4" - 5-5/8", HD Worm

2шт.

49

1546052C1

STRAP

2шт.

50

386170C1

CABLE TIE,.30" x 27 1/2"

1шт.

51

411241A3

STRAP

1шт.

52

326511A1

STRAP

1шт.

53

409-7616

BOLT,Hex Flg, 3/8" - 16 x 1", Spcl

1шт.

54

247780

SERRATED NUT,Flg, USR, 3/8"-16

2шт.

55

413-696

BOLT,Hex, 3/8" - 16 x 6", Gr 5

4шт.

56

87016

WASHER,0.41" ID x 0.81" OD x 0.07" Thk

2шт.

57

86625064

NUT,Prev Torque, 3/8" - 16, Gr B

1шт.

58

143493A2

BAR

2шт.

59

232-53112

FLANGE NUT,Flg, 3/4"-10

2шт.

60

232-5318

FLANGE NUT,Flg, 1/2"-13

1шт.

61

409-7824

BOLT,Hex Flg, 1/2" - 13 x 1 1/2", Spcl

3шт.

62

446112A1

BRACKET

2шт.

63

137882A1

PIN

5шт.

64

120903A1

SUPPORT

3шт.

65

128503A2

BRACKET

3шт.

66

446109A2

BAR

1шт.

67

446116A2

BRACKET

5шт.

68

189300A1

BRACKET

1шт.

69

446114A2

BRACKET

13шт.

70

409-7820

BOLT,Hex Flg, 1/2" - 13 x 1 1/4", Spcl

5шт.

71

136-166

COTTER PIN,Int, 9/32" x .120"

1шт.

72

409-7812

BOLT,Hex Flg, 1/2" - 13 x 3/4", Spcl

3шт.

73

439-11040

HEADED PIN,5/8" x 2", G2

2шт.

74

87016

WASHER,0.41" ID x 0.81" OD x 0.07" Thk

3шт.

75

409-7816

BOLT,Hex Flg, 1/2" - 13 x 1", Spcl

4шт.

76

413-656

BOLT,Hex, 3/8" - 16 x 3-1/2", Gr 5

4шт.

77

86625064

NUT,Prev Torque, 3/8" - 16, Gr B

2шт.

78

86512371

SERRATED NUT,Flg, USR, 1/2"-13

1шт.

79

87345109

STEP

6R Drum, #1

1шт.

80

87345110

STEP

Drum #2

1шт.

81

445286A1

GRAB RAIL

Drum Step

6шт.

82

892-11012

LOCK WASHER,M12

6шт.

83

614-12025

BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd

4шт.

84

409-7640

BOLT,Hex Flg, 3/8" - 16 x 2 1/2", Spcl

8шт.

85

247780

SERRATED NUT,Flg, USR, 3/8"-16

2шт.

86

87518974

SPACER

40шт.

87

514-1228

BOLT,Hex, M20 x 1.5 x 200mm, Cl 10.9

1шт.

88

87347426

PIPE

1шт.

89

413-632

BOLT,Hex, 3/8" - 16 x 2", Gr 5

1шт.

90

231-4116

NUT,3/8"-16, GB

1шт.

91

282112A4

DOOR

Rear Rotor

2шт.

92

1326408C2

STUD,25.4mm OD x 52.3mm L

12шт.

93

495-81023

WASHER,17/32" x 1 1/4" x .030"

2шт.

94

1326407C1

RETAINER

1шт.

95

84175359

SERVICE MANUAL

1шт.

Выбрано товаров: 95
