Запчасти Case IH 420 TIER 3 (09F-05) - SHIELDS, FUEL TANK (12) - CHASSIS

1

87729498

COVER ASSY

Left Hand

1шт.

2

87699687

COVER ASSY

Right hand

1шт.

3

87699682

COVER ASSY

2шт.

4

1990376C3

SUPPORT

1шт.

5

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

Side

27шт.

6

409-7512

BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl

28шт.

7

413-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5

6шт.

8

409-748

BOLT,Hex Flg, 1/4" - 20 x 1/2", Spcl

4шт.

9

84125478

SCREEN

Side

1шт.

10

87699684

COVER ASSY

1шт.

11

87496917

AIR CLEANER

1шт.

12

87699558

PLATE ASSY.

Bottom

1шт.

13

87699570

PLATE ASSY.

1шт.

14

409-7516

BOLT,Hex Flg, 5/16" - 18 x 1", Spcl

10шт.

15

238-6016

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

3шт.

16

201-123

HYD CONNECTOR,1"-14, Blkhd, ORFS

1шт.

17

201-919

BHD LOCK NUT,1" - 14

1шт.

18

1988957C1

HOSE

1шт.

19

201-343

ELBOW,90 Degree Elbow, 1" - 14 Male ORFS x 3/4" - 16 Male ORB

1шт.

20

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1шт.

21

495-11106

WASHER,1", SAE

1шт.

22

492-11050

LOCK WASHER,1/2"

6шт.

23

425-108

NUT,1/2" - 13, Gr 5

6шт.

24

188029C1

LATCH

2шт.

25

87730213

FOAM

1шт.

26

87730214

FOAM

1шт.

27

87496197

SEAL, GLASS

2шт.

28

87474580

1шт.

29

231-5144

SERRATED NUT,Flg, USR, 1/4"-20

4шт.
