Запчасти Case IH 2555 (09C-19) - AIR DUCTS AND HOSES -JJC0157149 (15) - HANDLING SYSTEM

4 Row Wide

1шт.

1

1988742C1

TUBE

No. 2 Front, Upper

1шт.

2

1988747C1

TUBE

No. 3 Rear

1шт.

3

1988871C1

TUBE,127.9 mm ID, 124.6 mm OD

No. 1 Rear

1шт.

4

1988872C1

TUBE

No. 1 Front, No. 4 Rear

2шт.

5

1988873C1

TUBE

No. 2 Rear

1шт.

6

1988874C1

TUBE

No. 3 Front

1шт.

7

1988876C1

TUBE,127.9 mm ID, 124.6 mm OD

No. 4 Front

1шт.

8

1984190C1

AIR HOSE

No. 1 Front, 1651 mm (65 in), Cut From 1349877CX

1шт.

9

1984191C1

AIR HOSE

No. 1, No. 2, No. 4 Rear, No. 3, No. 4 Front, 1473 mm (58 in), Cut From 1349877CX

5шт.

10

1984192C1

AIR HOSE

No. 3 Rear, Cut From 1349877CX

1шт.

11

112424A2

AIR HOSE,127.00 mm ID x 1371.60 mm

No. 2 Front, Cut from 1349877CX

1шт.

12

214-3188

HOSE CLAMP,4-3/4" - 5-5/8", HD Worm

16шт.

12a

254021A1

HOSE PROTECTION

No. 2 Rear, No. 3 Front

2шт.

12b

254022A1

HOSE PROTECTION

No. 1 Front and Rear, No. 4 Front and Rear

4шт.

12c

254023A2

HOSE PROTECTION

No. 2 Front, No. 3 Rear

2шт.

4 Row Wide

1шт.

13

1988744C2

TUBE,124.6 mm OD

No. 2 Front, Lower

1шт.

14

1988742C1

TUBE

No. 2 Front, Upper

1шт.

15

1988746C1

PIPE

No. 3 Rear

1шт.

16

1988747C1

TUBE

No. 3 Front

1шт.

17

1988749C1

PIPE

No. 4 Rear

1шт.

18

1988871C1

TUBE,127.9 mm ID, 124.6 mm OD

No. 1 Rear

1шт.

19

1988872C1

TUBE

No. 1 Front, No. 5 Rear

2шт.

20

1988873C1

TUBE

No. 2 Rear

1шт.

21

1988874C1

TUBE

No. 4 Front

1шт.

22

1988876C1

TUBE,127.9 mm ID, 124.6 mm OD

No. 5 Front

1шт.

23

1266304C3

HOSE,127.00 mm ID x 685.80 mm

No. 2 Front, Cut From 1349877CX

1шт.

24

1338078C3

AIR HOSE,127.00 mm ID x 889.00 mm

No. 4 Rear, Cut From 1349877CX

1шт.

25

1984190C1

AIR HOSE

No. 1 Front, 1651 mm (65 in), Cut From 1349877CX

1шт.

26

1984191C1

AIR HOSE

No. 1, No. 2, No. 5 Rear, No. 4, No. 5 Front, 1473 mm (58 in), Cut From 1349877CX

5шт.

27

1984192C1

AIR HOSE

No. 3 Front and Rear, Cut From 1349877CX

2шт.
