Запчасти Case IH 2555 (08-19) - HYDRAULIC MANIFOLD VALVE WITH 6.3 GPM DRUM LUBE FLOW (07) - HYDRAULICS

1986598C5

VALVE

Consists Of 1 - 53

1шт.

1

1288972C1

SOLENOID VALVE

Basket Door Lower

1шт.

2

1288972C1

SOLENOID VALVE

Basket Door Raise

1шт.

3

1288972C1

SOLENOID VALVE

Compactor Lower

1шт.

4

1288972C1

SOLENOID VALVE

Compactor Raise

1шт.

5

1288972C1

SOLENOID VALVE

Drum Field Pressure

1шт.

6

1288972C1

SOLENOID VALVE

Drum Field Tank

1шт.

7

1288972C1

SOLENOID VALVE

Drum Service Tank

1шт.

8

1288972C1

SOLENOID VALVE

Drum Service Pressure

1шт.

9

1288972C1

SOLENOID VALVE

Includes 9A, Drum Lube

1шт.

9a

149942C1

SEAL KIT

Seal Replacement, Not Illustrated

1шт.

10

107467A2

ORIFICE

1шт.

12

1542812C2

VALVE

Includes 12A

2шт.

12a

1272308C1

SEAL KIT

Seal, Flow Control, Not Illustrated

1шт.

13

1346479C2

VALVE

Right Hand Drum Lift

1шт.

14

1346479C2

VALVE

Left Hand Drum Lift

1шт.

15

1346479C2

VALVE

Includes 15A

1шт.

15a

1272308C1

SEAL KIT

Seal, Flow Control, Not Illustrated

1шт.

1340843C1

SOLENOID,12V

Includes 1 - 9, 16 - 21, 34 - 37, 43, 44

1шт.

1986598C5

VALVE

Continued From Previous Page

1шт.

16

1288958C1

VALVE

Left Hand Manual Drum Lift

1шт.

17

1288958C1

VALVE

Rockshaft Tiltback

1шт.

18

1288958C1

VALVE

Rockshaft Rollout

1шт.

19

1288958C1

VALVE

Right Hand Manual Drum Lift

1шт.

20

1288958C1

VALVE

Basket Raise

1шт.

21

1288958C1

VALVE

Unloader Motor

1шт.

22

1288958C1

VALVE

Left Hand Auto Drum Lift

1шт.

23

1288958C1

VALVE

Includes 23A, Right Hand Auto Drum Lift

1шт.

23a

1260872C91

SEAL KIT

Seal Replacement, Not Illustrated

1шт.

24

9625178

PLUG,9/16" - 18 ORB

Incl. 24A

5шт.

24a

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

1шт.

1341811C1

SPRING-CHECK

REPAIR KIT , Consists Of 25, 25A, Sense Check

13шт.

25

278548

PLUG,Hex, 7/16"-20 ORB

10шт.

25a

237-6004

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

Not Illustrated

1шт.

26

107416A1

PLUG

2шт.

1341807C1

SOLENOID

Includes 22, 23

1шт.

1340843C1

SOLENOID,12V

Includes 1 - 9, 16 - 21, 34 - 37, 43, 44

1шт.

1986598C5

VALVE

Continued From Previous Page

1шт.

27

201-304

ELBOW,90 Degree Elbow, 11/16" - 16 Male ORFS x 9/16" - 18 Male ORB

Includes 27A, 27B

1шт.

27a

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

Not Illustrated

1шт.

27b

238-6012

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

Not Illustrated

1шт.

28

107418A1

PLUG

1шт.
