Артикул
Название
Примечание
Количество
1
199601A4
CHUTE
Double, Upper
2шт.
2
127588A1
CLAMP
Upper
2шт.
2a
127589A1
CLAMP
Lower
2шт.
3
231-5146
FLANGE NUT,3/8"-16
1шт.
4
413-432
BOLT,Hex, 1/4" - 20 x 2", Gr 5
8шт.
5
230-4114
NUT,1/4"-20, GA
1/4
8шт.
6
1349872C3
DIVIDER
Double Chute
2шт.
7
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
5/16 x 1/2
1шт.
8
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
1шт.
9
495-81114
WASHER,8.74mm ID x 19.05mm OD x 1.7mm Thk
11/32 x 3/4 x 1/16
1шт.
10
1349843C1
HINGE
Female, Upper
12шт.
11
1270014C1
HINGE
Male
12шт.
12
1349860C1
PIN,7.94mm OD x 129mm L
Hinge
12шт.
13
432-816
COTTER PIN,1/8" x 1"
12шт.
14
199598A4
CHUTE
Single, Upper
2шт.
15
127588A1
CLAMP
Upper
2шт.
15a
127589A1
CLAMP
Lower
2шт.
16
1983180C1
COVER
Duct Access
1шт.
17
129-409
WING NUT,1/4"-20
1шт.
18
1984139C3
CHUTE
Female, Outer
6шт.
18a
231-4116
NUT,3/8"-16, GB
3/8
6шт.
19
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
12шт.
20
123567A1
SUPPORT
Air Hose
4шт.
20
196609A1
BRACKET
Used On Machines With Dual Wheels, Air Hose
4шт.
21
434-58
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1/2", Gr 5
12шт.
22
1349803C1
CHUTE
Male, Lower
6шт.
23
131427A2
SHEET
Lower Front
6шт.
24
131428A2
SHEET
Lower Rear
6шт.
25
1984343C1
HOOK
1шт.
27
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
1шт.
28
242378A2
HOOD
Outer, Double
2шт.
29
242372A2
COWL
Outer, Single
2шт.
30
123569A1
SUPPORT
Air Hose, Lower
2шт.
31
434-512
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 3/4", Gr 5
4шт.
32
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
4шт.
33
131425A2
SHEET
Upper
2шт.
34
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
5/16 x 1/2
14шт.
35
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
14шт.
36
233320A2
PIN,7.94mm OD x 194.5mm L
Used With Single Conveyor Chute and Hood
1шт.
37
233321A2
PIN,7.94mm OD x 366.5mm L
Used With Double Conveyor Chute and Hood
1шт.
38
136-159
HAIR PIN COTTER,Int, 3/16 x .080"
2 used per Hinge Pin
1шт.
39
195-81027
WASHER,0.38" ID x 1.12" OD x 0.07" Thk
2 Used Per Chute and Hood
1шт.
40
425-105
NUT,5/16"-18, G5
2 used per chute
1шт.
41
360662A1
NUT
5/16, 2 Used Per Hood
1шт.
42
320943A1
DEFLECTOR
6шт.
Выбрано товаров: 46
