Запчасти Case IH 2555 (09A-29A) - PLANT COMPRESSOR - ASN JFG010001 (13) - PICKING SYSTEM
№
Артикул
Название
Примечание
Количество
1
442695A1
GUIDE
Right Hand Front, Inc. 2
1шт.
2
404983A2
BUSHING,10.3mm ID x 18.1mm OD x 20mm L
2шт.
3
442696A1
GUIDE
Right Hand Rear, Inc. 4
1шт.
4
404983A2
BUSHING,10.3mm ID x 18.1mm OD x 20mm L
2шт.
5
404985A3
EXTENSION Front, Inc. 7, 7A - 7D
1шт.
6
434250A2
EXTENSION
EXTENSION Rear, Inc. 7, 7A - 7D
1шт.
7
160638C2
HANDLE
1шт.
7a
87426044
SPRING
SPRING Compression
2шт.
7b
87434457
PIN,9.52mm OD
PIN
1шт.
7c
87426046
PIN,9.52mm OD
PIN
1шт.
7d
38-1812
LOCK PIN,1/8" x 3/4", Slotted
1/8" x 3/4", Slotted
1шт.
8
216542C1
HUB
Torsion
2шт.
9
485-1258
SET SCREW,Sq Hd, 1/4"-20 x 1/2"
1/4 x 1/2
4шт.
10
413-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5
2шт.
11
216544C1
BUSHING
6шт.
12
86982778
SPACER,15.8mm ID x 21.34mm OD x 46.02mm L
5/8 ID x 1-13/16
1шт.
13
1982784C1
TORSION BAR
Torsion, Front
1шт.
14
1982785C1
TORSION BAR
Torsion, Rear
1шт.
15
669752R1
ADJUSTMENT ROD
Adjusting, Front
2шт.
16
216543C1
ADJUSTMENT ROD
Adjusting, Rear
2шт.
17
495-21044
WASHER,3/8"
(7/16 x 1 x 5/64)
4шт.
18
432-812
COTTER PIN,3/4" OAL x 1/8" W
4шт.
19
131-463
NUT,3/8"-16
4шт.
20
1338869C1
SPRING
Extension
2шт.
25
1982806C2
SUPPORT
1шт.
26
281-34912
SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"
3/8 x 3/4
2шт.
27
231-5146
FLANGE NUT,3/8"-16
2шт.
30
216828C2
GUIDE
Left Hand
17шт.
31
216829C2
GUIDE
Right Hand
17шт.
32
413-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
34шт.
33
87058C1
BELLEVILLE WASHER
34шт.
37
87401078
PLATE
Scrapping, Shallow Ribbed, If Equipped
6шт.
37
87403481
PLATE
Scrapping, Deep Ribbed, If Equipped
6шт.
38
474-12510
SCREW,FLAT, 1/4" - 28 x 5/8"
1/4 NF x 5/8
18шт.
39
492-11025
LOCK WASHER,1/4"
18шт.
40
425-114
NUT,1/4"-28, G5
18шт.
41
1988622C3
GUARD
All Except 5 Row No. 3
1шт.
41
1988826C2
GUARD
5 Row No. 3 Only, Not Illustrated
1шт.
42
434-612
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 3/4", Gr 5
3/8 x 3/4
2шт.
43
231-5146
FLANGE NUT,3/8"-16
2шт.
Выбрано товаров: 40
