Запчасти Case IH 2055 (9C-30) - AIR DUCTS AND HOSES, ALL MODELS (15) - HANDLING SYSTEM

1

1270084C1

DUCT

- transition, left-hand and right-hand sides

2шт.

2

1270220C1

COVER

- access hole

2шт.

3

231-5144

SERRATED NUT,Flg, USR, 1/4"-20

2шт.

4

1270166C1

DUCT

- elbow

1шт.

5

495-11034

WASHER,5/16", SAE

5/16" SAE (flat, 11/32 x 11/16 x 1/16")

34шт.

6

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

34шт.

7

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

34шт.

8

1988729C1

DUCT

- air plenum, right-hand, without access hole

1шт.

8a

1988729C2

DUCT

- air plenum, right-hand, with access hole, no longer available, order item 8C, 1988729C3, duct with air deflectors

1шт.

8b

1270220C1

COVER

- access hole, used on items 8A, 8C and 24A, 1988729C2, 1988729C3 and 1988738C2 ducts

2шт.

8c

1988729C3

VENT

DUCT ASSEMBLY - air plenum, right-hand, with access hole

1шт.

8d

139713A1

DEFLECTOR

- air plenum duct, right-hand, outside

1шт.

8e

139712A1

DEFLECTOR

- air plenum duct, right-hand, inside

1шт.

10

495-11041

WASHER,0.406" ID x 0.812" OD x 0.065" W

(Flat, 13/32 x 13/16 x 1/16") 3/8", SAE

4шт.

11

650987C1

CLAMP

- retaining, air supply duct, replaces 650988C1 clamp

11шт.

12

413-636

BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5

11шт.

12a

495-21044

WASHER,3/8"

(flat, 7/16 x 1 x 5/64 inch) 3/8"

22шт.

13

131-822

NUT,3/8"-16

NUT - hex, self-locking, 3/8 inch NC

11шт.

14

1546033C1

CLAMP,127mm ID, 10.3mm Bolt Hole, P Type

- duct mounting 127 mm diameter

4шт.

15

409-7616

BOLT,Hex Flg, 3/8" - 16 x 1", Spcl

3шт.

16

231-1446

NUT,3/8" - 16, Gr 5

NUT - light hex, self-locking, 3/8 inch NC

2шт.

17

112449A1

SUPPORT

BRACKET - air supply duct, no. 2 drum, front, 4 row

1шт.

18

1546403C1

SUPPORT

BRACKET - air supply duct, no. 2 drum, front, 5 row

1шт.

19

175231A1

CAP

- plenum tube, 4 row (replaces cap 1988986C1)

2шт.

20

1990442C1

ANGLE

- duct support, rear

2шт.

21

1988854C2

ANGLE

- duct support (replaces angle 1988854C1)

2шт.

22

409-7512

BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl

- hex serrated flange, 5/16 NC x 3/4 inch

8шт.

23

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

16шт.

24

1988738C1

DUCT

- air plenum, left-hand, without access hole

1шт.

24a

1988738C3

VENT

DUCT - air plenum, left-hand, with access hole (replaces duct 1988738C2)

1шт.

24b

231-5144

SERRATED NUT,Flg, USR, 1/4"-20

2шт.

25

1546034C1

BRACKET

- clamp mounting

1шт.

26

495-11066

WASHER,5/8", SAE

- flat, 21/32 x 1-5/16 x 3/32 inch, 5 row

1шт.

27

434-512

CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 3/4", Gr 5

BOLT - carriage, 5/16 NC x 3/4 inch

12шт.
