Запчасти Case IH 2055 (9F-34) - DECALS, SAFETY (12) - CHASSIS

1

68819C1

CAUTION DECAL

DECAL, CAUTION, Battery

1шт.

2

87132C1

DECAL

- Warning, basket locks

3шт.

3

87133C1

DECAL

- Warning, drum locks

2шт.

4

204166C1

DECAL

- Caution, cooling

1шт.

5

210600C1

DECAL

- Danger, repair and cleaning

4шт.

6

216346C2

DECAL

- Warning, stay clear of spindles

4шт.

7

87185C2

DECAL

- Danger, wires and turning

1шт.

8

1285447C2

DECAL

- Danger, disengage harvesting unit

4шт.

9

1288828C1

DECAL

- Warning, avoid injury, keep off when the engine is running, pinch points occur when the basket moves up and down and when the compactor cycles

1шт.

10

2754442R1

PRODUCT GRAPHIC

DECAL - Caution, keep off while machine is in motion

1шт.

11

1326215C1

DECAL

- Warning, keep drive line shields in place

2шт.

12

2753929R5

DECAL

- Caution, for safe operation

1шт.

13

64553C2

PRODUCT GRAPHIC

DECAL - Warning, safety shield

2шт.

14

1329378C1

DECAL

- Danger, keep away from the basket door and chain when unloading

1шт.

15

1338616C2

DECAL

- Warning, a valve is provided to lower the basket lift cylinders when using the basket lift cylinders to raise the basket cover. There Should Be No Other Use Of This Valve (Replaces decal 1338616C1)

1шт.

16

111866A1

DECAL

- Warning, the tires on this machine are mounted on multi-purpose wheel rims

4шт.

17

321-7040

DANGER DECAL

DECAL, DANGER, Starting in gear can cause death

1шт.
