Запчасти Case IH 460 (092) - SIDE SHEETS AND DECK, TOOL BOX (39) - FRAMES AND BALLASTING

1

F85771

CHANNEL - cross, front

1шт.

14-820

BOLT,Hex, 1/2" - 20 x 1-1/4", Gr 5

- 1/2" x 1-1/4" N.F. hex.; nut (25-118) L.W. (92-8)

2шт.

14-825

BOLT - 1/2" x 1-1/2" N.F. hex.; nut (25-118) L.W. (92-8)

4шт.

2

F85757

SHEET - side, R.H. (Before #8361801)

1шт.

F89152

SHEET - side, R.H. (#8361801 and after)

1шт.

14-58

BOLT,Hex, 5/16" - 24 x 1/2", Gr 5, Full Thd

- 5/16" x 1/2" N.F. hex.; nut (25-115) L.W. (92-5)

1шт.

3

F41166

DECK - top

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.; nut (25-114) L.W. (92-4)

5шт.

14-48

BOLT,Hex, 1/4" - 28 x 1/2", Gr 5

; Nut (25-114), L.W. (92-4) and wshr. (195-18) Hex, 1/4"-28 x 1/2", G5, Full Thd

8шт.

14-510

SCREW,Hex, 5/16" - 24 x 5/8", Gr 5, Full Thd

BOLT, , Nut (25-115) L.W. (92-5) Hex, 5/16"-24 x 5/8", G5, Full Thd

2шт.

4

F85772

CHANNEL - top, body

1шт.

14-816

BOLT,Hex, 1/2" - 20 x 1", Gr 5

- 1/2" x 1" N.F. hex.; nut (25-118) L.W. (92-8)

1шт.

5

F85793

FILLER - rear deck

1шт.

114-102

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5

Nut (129-122) L.W. (192-20) Hex, 5/16"-24 x 3/4", G5, Full Thd

3шт.

114-105

BOLT,Hex, 5/16" - 24 x 5/8", Gr 5

Nut (129-122) L.W. (192-20) Hex, 5/16"-24 x 5/8", G5, Full Thd

2шт.

113-118

BOLT,Hex, 5/16" - 18 x 5/8", Gr 5

; L.W. (192-20) Hex, 5/16"-18 x 5/8", G5, Full Thd

4шт.

187-1006

SCREW,Hex Hd, 1/4" x 5/8"

BOLT - tapping, 1/4" x 5/8" N.C. hex.; wshr. (195-5/8)

1шт.

114-3

BOLT,Hex, 1/4" - 28 x 5/8", Gr 5

Nut (129-121) L.W. (192-19) Hex, 1/4"-28 x 5/8", G5, Full Thd

6шт.

6

F86525

CLIP

- access doors

28шт.

151-123

RIVET - 3/16" x 4/16" semi-tubular

28шт.

7

F85760

DECK - rear (Before #8361801)

1шт.

F84885

DECK - rear (#8361801 and after)

1шт.

F12794

STRIP - anti-skid (On rear deck)

4шт.

14-48

BOLT,Hex, 1/4" - 28 x 1/2", Gr 5

; Nut (25-114), L.W. (92-4) Hex, 1/4"-28 x 1/2", G5, Full Thd

12шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.; nut (25-114) L.W. (92-4)

14шт.

8

F41243

HANDRAIL

1шт.

14-510

SCREW,Hex, 5/16" - 24 x 5/8", Gr 5, Full Thd

BOLT, , Nut (25-115) L.W. (92-5) Hex, 5/16"-24 x 5/8", G5, Full Thd

2шт.

14-516

BOLT,Hex, 5/16" - 24 x 1", Gr 5, Full Thd

- 5/16" x 1" N.F. hex.; nut (25-115) L.W. (92-5)

1шт.

9

F84420

HOOD - rear

1шт.

114-2

BOLT,Hex, 1/4" - 28 x 1/2", Gr 5

- 1/4" x 1/2" N.F. hex.; nut (129-121) L.W. (192-19)

17шт.

195-102

WASHER,1/4"

- 1/4"

5шт.

114-5

BOLT,Hex, 1/4" - 28 x 3/4", Gr 5

- 1/4" x 3/4" N.F. hex.; nut (129-121) L.W. (192-19)

2шт.

114-3

BOLT,Hex, 1/4" - 28 x 5/8", Gr 5

Nut (129-121) L.W. (192-19) Hex, 1/4"-28 x 5/8", G5, Full Thd

10шт.

114-209

BOLT,Hex, 3/8" - 24 x 3/4", Gr 5

- 3/8" x 3/4" N.F. hex.; nut (129-123) L.W. (192-21)

2шт.

10

F91841

LADDER - (Replaces F82410 when stocks exhausted)

1шт.

F82410

LADDER - (Replaced by F91841 when stocks exhausted)

1шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

Nut (25-115) L.W. (92-5) Hex, 5/16"-24 x 3/4", G5, Full Thd

3шт.

11

F8077

DOOR - access

2шт.

12

F85773

BRACE - L.H. side sheet

1шт.

14-828

BOLT,Hex, 1/2" - 20 x 1-3/4", Gr 5

- 1/2" x 1-3/4" N.F. hex.; nut (25-118) L.W. (92-8)

2шт.

13

F16580

DOOR - access

6шт.

14

F19954

BRACKET - stiffener, L.H.

1шт.

F19955

BRACKET - stiffener, R.H.

1шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

Nut (25-115) L.W. (92-5) and wshr. (195-21) Hex, 5/16"-24 x 3/4", G5, Full Thd

1шт.

O3902

SPACER - (1/4" x 13/16" pipe)

1шт.

O1594N

WASHER

1шт.

14-524

BOLT,Hex, 5/16" - 24 x 1-1/2", Gr 5

- 5/16" x 1-1/2" N.F. hex.; nut (25-115) L.W. (92-5)

1шт.

15

F85754

SHEET - side, L.H. (Before #8361801)

1шт.

F89150

SHEET - side, L.H. (#8361801 and after)

1шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

Nut (25-115) L.W. (92-5) Hex, 5/16"-24 x 3/4", G5, Full Thd

1шт.

16

F84380

BOX - tool

1шт.

114-105

BOLT,Hex, 5/16" - 24 x 5/8", Gr 5

- 5/16" x 3/4" N.F. hex.; nut (129-122) L.W. (192-20), tool box

2шт.

17

F20294

BRACE - support, tool box

1шт.

14-510

SCREW,Hex, 5/16" - 24 x 5/8", Gr 5, Full Thd

BOLT, , Nut (25-115) L.W. (92-5), Tool box Hex, 5/16"-24 x 5/8", G5, Full Thd

1шт.

114-105

BOLT,Hex, 5/16" - 24 x 5/8", Gr 5

- 5/16" x 3/4" N.F. hex.; nut (129-122) L.W. (192-29), tool box

1шт.
