Запчасти Case IH 400 (003) - CHAINS AND BELTS (05) - SERVICE & MAINTENANCE

B15926

LINK

CHAIN - weed seed auger drive (10 ft. roll #25 steel chain)

1шт.

F8655

X

CHAIN - lower roller drive (Draper Pickup attachment) use (2) B12483 chains, (2) B12485 chains, (1) B12512 conn. link, (1) B12513 roller link and (3) B12515 off-set links #CA2040

1шт.

F16079

X

CHAIN - fan jackshaft (47 total links - Use (2) B12486 chains, (1) B12488 chain and (1) B12515 offset link #A2040 extended pitch roller chain)

1шт.

F16228

X

CHAIN - drives rocker arm crankshaft (Use (2) B12478 chains and (4) B12481 chains #50)

1шт.

F16252

X

LINKS - extension, cylinder chain (Use (2) B12511 roller links and (1) B12509 conn. link #60)

2шт.

F16442

X

CHAIN - grain elevator drive (Use (3) B12486 chains, (1) B12514 conn. link and (3) B12516 roller links #AG2040 roller chain)

1шт.

F17105

X

CHAIN - discharge auger drive (Use (1) B12486 chain, (1) off-set link and (1) B12516 roller link #AG2040 roller chain)

1шт.

F17514

X

CHAIN - short extension (Use (3) B12503 roller links #40)

1шт.

F17924

X

CHAIN - drives drive jackshaft (Use (1) B12473 chain and (1) roller link #40)

1шт.

F18520

X

CHAIN - cylinder drv. (Use (1) B12478 chain, (1) B12480 chain, (1) B12481 chain, (4) B12509 conn. links, (1) B12510 offset link and (2) B12511 roller links #60)

1шт.

F20636

CHAIN - auger drive (Use (2) B12474 chains, (1) B12475 chain, (1) B12476 chain, (2) B12505 conn. links and (3) B12506 offset links #50)

1шт.

F20637

CHAIN - reel drive (Use (1) B12470 chain, (1) B12473 chain, (1) B12501 conn. link, (1) B12502 offset link, (1) B12503 roller link #40)

1шт.

F51206

ROLLER

CHAIN - distribution auger drive (Use (1) B12470 chain, (2) B12472 chains, (1) B12473 chain and (1) B12502 off-set link #40 roller chain)

1шт.

F16080

V-BELT

Variable Speed, Fan Drive

1шт.

F16744

V-BELT

BELT - rear roller drive

1шт.

F16745

V-BELT

BELT - jackshaft drive

1шт.

F17445

V-BELT

BELT - jackshaft

1шт.

F16447

V-BELT

Tailings Drive

1шт.

F19549

V-BELT,153.00" L

Front Cutter Spreader Drive 153.00" L

1шт.

F19550

V-BELT

BELT - rear (73") cutter and spreader drive

1шт.

F20628

BELT - sickle

1шт.

F20712

SCREW

BELT - drive, main combine (Before #8262501)

1шт.

F20721

SCREW

BELT - header drive

1шт.

F20722

SCREW

BELT - grain bin drive

1шт.

F20741

SCREW

BELT - beater drive

1шт.

F40621

BELT - drive, main combine (#8262501 and after)

1шт.
