Запчасти Case IH 960 (344) - SPECIAL WIDE REAR AXLE, GRAIN COMBINE (27) - REAR AXLE SYSTEM

1

F82711

SUPPORT - rear axle tube

1шт.

A27339

GROMMET

1шт.

BOLT - 3/8" x 3/4" N.F. hex. (14-612) Nut (25-116) L.W.

6шт.

BOLT - 3/8" x 2-3/4" N.F. hex. (14-644) Nut (25-116)

8шт.

2

F83340

COLLAR - for ref. 1 support

1шт.

3

F20025

BRACKET - hydraulic hose

1шт.

BOLT - 7/16" x 1-1/4" N.F. hex. (14-720) Stop nut (131-7)

2шт.

4

F13053

SCREW

OIL SEAL - wheel hub

2шт.

5

F57452

CONE - inner bearing, wheel hub

2шт.

6

F77895

HUB - wheel

2шт.

7

G57451

BEARING, CUP

CUP - inner bearing, wheel hub

1шт.

8

B12410

BEARING, CUP,1.782" OD

CUP - outer bearing, wheel hub

1шт.

9

B12411

ROLLER BEARING,0.75" ID x 0.655"

CONE - outer bearing, wheel hub

2шт.

10

B13280

HUB CAP

CAP - hub, wheel

2шт.

11

F18801

MAKING-UP

WHEEL - (For 6:00 x 16 or 6:50 x 16, 4 ply tire)

2шт.

F8873

WHEEL - (For 6:60 x 16, 4 ply tire)

2шт.

12

A31040

WHEEL BOLT,9/16" - 18 x 1 13/32", Gr 5

BOLT -, Serial Range: wheel-hub

12шт.

13

F76779

SPINDLE - R.H. steering

1шт.

126-40

WOODRUFF KEY,#G, 3/8" x 1 1/2"

1шт.

NUT - 1" N.F. hex. jam (25-1516) L.W. (92-16)

1шт.

14

F82802

SPINDLE - L.H. steering

1шт.

126-40

WOODRUFF KEY,#G, 3/8" x 1 1/2"

1шт.

NUT - 1" N.F. hex. jam (25-1516) L.W. (92-16)

2шт.

15

25-1912

SLOTTED NUT,3/4"-16, G5, Thk

NUT - 3/4" N.F. hex. slotted, spindle

2шт.

PIN - cotter 1/8" x 1-1/4" (132-50)

2шт.

16

A30054

THRUST BEARING,35.18mm ID x 58.74mm OD x 15.88mm W

BEARING - spindle

2шт.

17

A30074

HOSE

WASHER - thrust lower

2шт.

18

A29467

SHIM,.010" Thk

Adjusting .010" Thk

1шт.

19

F3121

ARM - L.H. spindle

1шт.

20

F3120

ARM - R.H. spindle

1шт.

21

F82800

AXLE - rear (66" wide axle)

1шт.

F91959

AXLE - rear (78" wide axle)

1шт.

22

F11016

BUSHING - (Used with F82800)

4шт.

22a

F14814

BUSHING - (Used with F91959)

4шт.

22b

F14813

SPACER - bushing (Used with F91959)

2шт.

219-36

LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF

FITTING - 1/8" - 45 degree grease (Axle)

2шт.

219-40

LUBE NIPPLE,65 Degree Elbow, 1/8" - 27 NPTF

FITTING - 1/8" - 67-1/2 degree grease

1шт.

23

F22496

TUBE - tie rod (78" wide axle)

1шт.

F12739

HOUSING

TUBE - tie rod (66" wide axle)

1шт.

24

F86782

END - R.H.

1шт.

25

25-1416

NUT,Jam, 1"-8, G5

- 1" N.C. hex. jam R.H. thrd.

1шт.

26

F86783

END - L.H.

1шт.

27

129-350

NUT - 1" N.C. hex. jam L.H. thrd.

1шт.

28

25-139

SLOTTED NUT,9/16"-18, G5

NUT - 9/16" N.F. slotted hex., tie rod

2шт.

132-48

COTTER PIN,1/8" x 1"

Pin, Split (Cotter), 1/8" x 1"

2шт.
