Запчасти Case IH 960 (288) - VARIABLE SPEED TRACTION DRIVE INDICATOR NO. 8334601 AND AFTER (16) - TRACTION VARIATOR

1

F1581

BRACKET - support, tightener arm

1шт.

BOLT - 3/8" x 1-3/4" N.F. hex. (14-628) Nut (25-116)

2шт.

LOCKWASHER - 3/8" (92-6)

2шт.

BOLT - 5/16" x 1-1/4" N.F. hex. (14-520) Nut (25-115)

2шт.

LOCKWASHER - 5/16" (92-6)

2шт.

2

F18647

STUD - pivot, support bracket

1шт.

132-95

COTTER PIN,3/16" x 1 1/2"

Pin, Split (Cotter), 3/16" x 1 1/2"

1шт.

132-101

PIN,3/16" x 2 1/4"

Split (Cotter), 3/16" x 2 1/4"

1шт.

3

O906B

WASHER

- tightener arms

1шт.

4

F1711

SHEAVE - engine output (#8323601 thru #8358000)

1шт.

F2214

SHEAVE - engine output (#8358001 and after)

1шт.

4

F1463

SHEAVE

- engine output (Before #8323601)

1шт.

PIN - cotter 3/16" x 2" (132-99)

1шт.

126-129

WOODRUFF KEY,#C, 5/16" x 1 1/8", HT

1шт.

5

F20472

GUARD - belt, main combine drive

2шт.

BOLT - 5/16" x 3/4" N.F. hex. (14-512) Nut (25-115)

2шт.

LOCKWASHER - 5/16" (92-5)

2шт.

6

F17946

GAUGE - spring, traction drive

1шт.

7

232EB

SPRING - traction drive idler adjustment

1шт.

8

O58BL

WASHER - adjustment rod

1шт.

9

F19583

BUSHING - for tension rod

1шт.

10

F17459

ROD

- tension, traction drive belt tightener (Before #8358511)

1шт.

F22708

PLOW BOLT

ROD - tension, drive belt tightener (#8358511 and after)

1шт.

NUT - 5/16" N.C. hex. (25-105) Fl. wshr. (195-21)

2шт.

132-25

COTTER PIN,3/32" x 5/8"

Pin, Split (Cotter), 3/32" x 5/8"

1шт.

11

F20033

BELT

Primary Variable Speed Traction Drive, Before Serial No. 8358001

1шт.

F22821

"V" BELT - primary traction drive (#8358001 and after)

1шт.

11

F20854

BELT

- primary drive (Slow ground speed attach) (Before #8358001)

1шт.

12

F94336

SHEAVE

- (Balanced assemblies)

1шт.

12a

F1452

SHEAVE - stationary half (Before #8358001)

1шт.

12a

F1681

SHEAVE - stationary half (#8358001 and after)

1шт.

12a

F1681

SHEAVE - stationary half (Slow ground speed attach) (Before #8358001)

1шт.

13

F1583

ARM

- tightener, (w/o air conditioner) Before #8358511

1шт.

13a

F94202

ARM - tightener (w/o air conditioner) #8358511 and after

1шт.

13b

F11666

BEARING - for F94202

1шт.

13c

F87964

ARM - tightener, traction drive (With air conditioner)

1шт.

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, 1/4"-28 NPT x .54" lg

1шт.

14

F80073

PULLEY ASSY.

SHEAVE - (8") idler

1шт.

13-1048

BOLT,Hex, 5/8" - 11 x 3", Gr 5

Nut (25-1010) Hex, 5/8"-11 x 3", G5

1шт.

LOCKWASHER - 5/8" (92-10)

1шт.

15

F83075

ARM - tightener, idler sheave (Before #8358001)

1шт.

F94199

ARM - tightener, idler sheave (#8358001 and after)

1шт.

132-99

COTTER PIN,3/16" x 2"

Pin, Split (Cotter), 3/16" x 2"

1шт.

219-87

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, 1/4"-28 x .56" lg, Self-Tap

1шт.

16

F17518

SPACER - belt crank arms

1шт.

O3277BF

SPACER

1шт.
