Запчасти Case IH 960 (104) - ROTATING FAN SCREEN ATTACHMENT (10) - ENGINE

1

F21237

WASHER - screen hub

2шт.

2

W5063S

KEY

- screen, Serial Range: hub-shaft

2шт.

3

F21056

SCREEN - rotating

2шт.

4

F20864

HUB - screen

2шт.

SCREW - 5/16" x 3/4" cup pt. set (83-512)

4шт.

BOLT - 1/4" x 1" N.F. hex. (114-1) L.W. (192-19)

8шт.

5

F20862

BRACKET - rear, wrapper

2шт.

BOLT - 1/4" x 1/2" N.F. hex. (114-2) Nut (129-121)

4шт.

LOCKWASHER - 1/4" (192-19)

4шт.

6

F83963

CLOSURE - upper R.H.

1шт.

BOLT - 1/4" x 1/2" N.F. hex. (114-2) Nut (129-121)

8шт.

LOCKWASHER - 1/4" (192-19)

8шт.

BOLT - 5/16" x 3/4" N.F. hex. (114-102) Nut (129-122)

1шт.

7

F20992

BRACE - shield (Use w/R.H. drive shield)

1шт.

BOLT - 1/4" x 3/4" N.C. hex. (113-3) L.W. (192-19)

2шт.

8

F83964

COVER - upper, R.H. closure

1шт.

BOLT - 1/4" x 1/2" N.C. hex. (113-1) L.W. (192-19)

6шт.

9

F20858

CLOSURE - upper, L.H.

1шт.

BOLT - 1/4" x 1/2" N.F. hex. (114-2) Nut (129-121)

2шт.

LOCKWASHER - 1/4" (192-19)

2шт.

BOLT - 1/4" x 3/8" N.F. hex. (114-9) Nut (129-121)

4шт.

LOCKWASHER - 1/4" (192-19)

4шт.

10

F20860

WRAPPER - L.H.

1шт.

11

F21893

SHAFT - fan

1шт.

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - grease, 1/8" str.

1шт.

12

F20861

BRACKET - front, wrapper

2шт.

BOLT - 1/4" x 1/2" N.F. hex. (114-2) Nut (129-121)

4шт.

LOCKWASHER - 1/4" (192-19)

4шт.

13

F20863

BRACKET - lower, wrapper

2шт.

BOLT - 1/4" x 1/2" N.F. hex. (114-2) Nut (129-121)

4шт.

14

F20859

WRAPPER - R.H.

1шт.
