Запчасти Case IH 800 (192) - PISTONS AND CONNECTING RODS (10) - ENGINE
№
Артикул
Название
Примечание
Количество
A7207
SLEEVE CYLINDER
LINERS - connecting rod bearing, top & bottom half (.002" undersize)
4шт.
A7209
X
LINERS - connecting rod bearing, top & bottom half (.010" undersize)
4шт.
A7211
X
LINERS - connecting rod bearing, top & bottom half (.020" undersize)
4шт.
A7213
SLEEVE CYLINDER
LINERS - connecting rod bearing, top & bottomg half (.030" undersize)
4шт.
A7526
OIL SEAL
RING - piston, top (see note)
4шт.
A7527
OIL SEAL
RING - piston, second and third (see note)
8шт.
A8095
KIT
RINGS - piston, set of (16) perfect circle 2-in-1 chrome
1шт.
A11110
X
SLEEVE - cylinder
4шт.
A20393
LINING
LINERS - connecting rod bearing, top & bottom half (std. size)
4шт.
A21515
X
PISTON (see A22192)
4шт.
A21721
BUSHING
SET OF 2 - 09716AB piston pin bushings
2шт.
A21723
PIN
SET OF 2 - 09713AB piston pins and 4 - 09714AB retainers
2шт.
A22192
SET OF 2 CYLINDER SLEEVES, pistons, rings and piston pins
2шт.
4603AA
X
ROD - connecting, with cap, bushing and capscrews
4шт.
09712AB
"O" RING - cylinder sleeve
8шт.
09713AB
PIN - piston (use A21723)
1шт.
09714AB
RING - piston pin retainer (see A21723)
8шт.
09716AB
BUSHING - piston pin (use A21721)
1шт.
09718AB
CAPSCREW - connecting rod
8шт.
A7134
FLYWHEEL (use A20876), crankshaft
1шт.
A7182
KIT
LINERS - crankshaft bearing (wide - upper & lower) (.002" undersize)
3шт.
A7188
BEARING LINER
LINERS - crankshaft bearing (wide - upper & lower) (.010" undersize)
3шт.
A7194
KIT
LINERS - crankshaft bearing (wide - upper & lower) (.020" undersize)
3шт.
A7200
KIT
LINERS - crankshaft bearing (wide - upper & lower) (.030" undersize)
3шт.
A7204
WASHER
- crankshaft thrust (.006" oversize). see 09705AB
2шт.
A9791
RETAINER
- crankshaft rear oil seal, with dowel pins
1шт.
3/8" x 1-1/8" N.C. hex. bolt w/lockwasher, crankshaft
6шт.
A20394
LINING
LINERS - crankshaft bearing (narrow - upper & lower) (standard size)
2шт.
A20579
LINING
LINERS - crankshaft bearing (narrow - upper & lower) (.002" undersize)
2шт.
A20582
LINING
LINERS - crankshaft bearing (narrow - upper & lower) (.010" undersize)
2шт.
A20585
KIT
LINERS - crankshaft bearing (narrow - upper & lower) (.020" undersize)
2шт.
A20588
KIT
LINERS - crankshaft bearing (narrow - upper & lower) (.030" undersize)
2шт.
A20875
GEAR, RING
GEAR - flywheel ring, crankshaft
1шт.
A20876
FLYWHEEL - with ring gear, crankshaft
1шт.
F3088
HUB - engine output shaft, crankshaft
1шт.
F7662
BOLT - dowel, flywheel, crankshaft
2шт.
F7663
BOLT - flywheel, crankshaft
4шт.
4706AA
X
LINERS - crankshaft bearing (wide - upper & lower). standard size
3шт.
6301A
CAP - crankshaft bearing, wide
2шт.
A6302A
X
CAP - crankshaft bearing, narrow
2шт.
6303A
CAP - crankshaft thrust bearing
1шт.
08651AB
KEY - Woodruff, for crankshaft
2шт.
09705AB
WASHER - crankshaft thrust (standard size) (see A7204)
2шт.
09706AB
SCREW - crankshaft bearing cap
10шт.
09707AB
GEAR - crankshaft
1шт.
09708AB
OIL SEAL - crankshaft, front
1шт.
09709AB
OIL seal - crankshaft, rear
1шт.
010700AB
CRANKSHAFT
1шт.
010701AB
GASKET - crankshaft rear oil seal retainer
1шт.
A7078
STEP BOLT
- dowel, cylinder block to flywheel housing, long
1шт.
1/2" N.F. hex. nut & lockwasher, flywheel and housing
1шт.
A7079
TUBE
BOLT - dowel, cylinder block to flywheel housing, short
1шт.
1/2" N.F. hex. nut and lockwasher, flywheel and housing
1шт.
A7081
BEARING
SHIELD - dust, flywheel housing
1шт.
1/2" x 1-1/4" N.F. hex. bolt w/hex. nut and lockwasher, flywheel and housing
4шт.
3/8" x 3/4" N.C. hex. bolt, flywheel and housing
4шт.
1/2" x 1-1/2" N.C. hex. bolt w/lockwasher, flywheel and housing
3шт.
1/2" x 1-3/4" N.F. hex. bolt w/hex. nut, flywheel and housing
3шт.
1/4" sq. hd. pipe plug, flywheel and housing
1шт.
A20108
BOLT - cylinder block to flywheel housing
2шт.
3/4" N.C. hex. nut and lockwasher, flywheel and housing
2шт.
Выбрано товаров: 63
