Запчасти Case IH 800 (239) - RADIATOR FRAME AND SCREEN (10) - ENGINE

F6181

SPRING - air screen

4шт.

F7738

CLIP - access door

2шт.

1/4" x 5/8" rd. hd. rivet

2шт.

F8077

DOOR - access, radiator stack

1шт.

F9300

SEAL - felt, radiator mounting

2шт.

F9318

ROD - hinge (15-3/4") radiator screen

1шт.

1/8" x 3/4" cotter pin

2шт.

F77548

STACK - radiator frame

1шт.

3/8" x 1" carr. bolts w/hex. nut and lockwasher

2шт.

F77554

AIR SCREEN - radiator

1шт.
