Запчасти Case IH 403 (403) - ENGINE COVER, LATCH AND SUPPORTS, FOR D-301 ENGINE, COMBINE SERIAL NO. 7223 AND BELOW (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

NOT USED IN THIS APPLICATION

1шт.

2

NOT USED IN THIS APPLICATION

1шт.

3

NOT USED IN THIS APPLICATION

1шт.

4

NOT USED IN THIS APPLICATION

1шт.

5

654574R11

COVER W/STRAP, engine, Combine serial no., Serial Range: 2196-4643

1шт.

5

936496R1

COVER, engine, Combine serial no. 4644 & above

1шт.

6

NOT USED IN THIS APPLICATION

1шт.

7

634107R1

POST, engine cover

1шт.

103384

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

1шт.

Q397

WASHER

11/32 X 3/4 X 16 GA WASHER

1шт.

8

633269R1

SEAL, engine cover hinge, Grain tank, Combine serial no. 4643 & below

1шт.

8

654940R1

SEAL

engine core hinge, Grain tank, Combine serial no. 4644 & above

1шт.

109084

NUT,1/4"-20, G5

14шт.

113957

SCREW,Sl Rnd Hd, 1/4" - 20 x 3/4"

1/4 X 3/4 SLT-RD-HD SCREW

14шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

14шт.

136661H

WASHER

17/64 X 1 X 16 GA WASHER

4шт.

9

634126R1

STIFFENER, engine cover seal, Grain tank, Serial no. 4643 & below

2шт.

9

654941R1

STIFFENER, engine cover seal, Grain tank, Serial no. 4644 & above

1шт.

10

633270R1

ROD, engine cover hinge

1шт.

103384

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

2шт.

557264R1

WASHER

11/32 X 3/4 X 11 GA WASHER

4шт.

11

634108R1

SUPPORT, engine cover hinge RH

1шт.

179820

BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5

2шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

12

U13039

SPACER

engine cover hinge rod

1шт.

13

654573R11

SUPPORT W/LATCH ASSY, engine cover RH rear, Includes ref no. 14

1шт.

14

353443R91

LATCH ASSY.

LATCH ASSY

2шт.

15

654570R91

SUPPORT W/LATCH ASSY, engine cover LH, Includes ref no. 14

1шт.
