Запчасти Case IH 1160 (07A) - AUGER OVER GRAIN BIN, GRAIN AUGER (80) - CROP STORAGE/UNLOADING

1

F88131

SPROCKET (18T) distribution auger driven (Before #8357001)

1шт.

F79467

SPROCKET ASSY.

SPROCKET (30T) distribution auger driven (#8357001 and after)

1шт.

2

F14525

CHAIN - elevator drive, use w/F88131 sprkt. (61 riveted, 1-offset and 1-conn. link) Use 1-B12470, 2-B12473 chains and 1-B12502 offset link #40 roller chain or cut from B13030

1шт.

F11247

CHAIN - elevator drive, use w/F79467 sprkt. (67 riveted, 1-offset and 1-conn. link) Use 1-B12470, 1-B12472, 1-B12473 chain, 1-B12503 roller, 1-B12502 offset and 1-B12501 conn. link #40 or cut from B13030 (See page 165 #B958 parts catalog)

1шт.

F88248

SHEAVE - drives grain auger and fan (In place of F86142), grain auger

1шт.

F12054

BUSHING, grain auger

1шт.

FITTING - 1/8" str. (219-1) (See page 169 #B958 parts catalog), grain auger

1шт.

F10269

BELT

Fan Drive, In Place of F9468, See Page 149 #B958 Parts Catalog, Grain Auger

1шт.
