Запчасти Case IH 1060 (16) - ENGINE TO PUMP DRIVE (29) - HYDROSTATIC DRIVE

1

F86738

DISC - drive (H-318 and LH-318 Chrysler)

1шт.

BOLT - 3/8" x 1" N.C. hex. (13-616) L.W. (92-6)

6шт.

2

F12657

SHAFT - engine output

1шт.

3

F12967

SPACER - for F12657 shaft

1шт.

4

O6267HT

KEY

- for F12657 shaft

1шт.

5

F87251

GUIDE - belt, engine pulley

1шт.

BOLT - 3/8" x 3" N.F. hex. (114-228) nut (129-123)

1шт.

BOLT - 1/4" x 1" N.F. hex. (114-1) nut (129-121)

1шт.

BOLT - 3/8" x 1-1/4" N.F. hex. (114-201) nut (129-123)

1шт.

6

F8025

BEARING

- F12657 shaft

1шт.

7

A27579

RING

SNAP RING

1шт.

8

F1960

HOUSING - engine output shaft

1шт.

9

F1962

SHEAVE - multiple drive

1шт.

10

F87232

WAY - pump mounting

1шт.

BOLT - 3/8" x 3-3/4" N.F. hex. (14-660) nut (25-116)

2шт.

BOLT - 3/8" x 1-1/4" N.C. hex (14-620) L.W. (92-6)

2шт.

11

O2437B

WASHER

2шт.

12

B18305

NUT

1шт.

PIN - 1/8" x 1-3/4" cotter (132-54)

1шт.

13

F87233

WAY - pump mounting

1шт.

BOLT - 3/8" x 3-3/4" N.F. hex. (14-660) nut (25-116)

2шт.

BOLT - 3/8" x 1-1/4" N.C. (14-620) L.W. (92-6)

2шт.

14

F87234

SPROCKET - drive (34T)

1шт.

BOLT - 9/16" x 1-1/2" N.F. hex. grade #5 (14-924) wshr. (195-33)

2шт.

15

F87235

SPROCKET - coupler

1шт.

16

F87236

SPROCKET - pump

1шт.

17

F87211

CHAIN - roller, engine coupler

2шт.

18

F1993

BASE - pump

1шт.

19

F87237

PUMP - hydrostatic

1шт.

BOLT - 5/8" x 2" N.C. hex (13-1032) L.W. (92-10)

2шт.

PLUG - (218-5156)

1шт.

PLUG - (218-5157)

1шт.

20

F14531

TERMINAL - pump control

1шт.

21

F14516

CLAMP - pump control

1шт.

NUT - 3/8" N.F. hex. jam

2шт.
