Запчасти Case IH 1060 (14) - F87855 CONTROL VALVE, PORT PLATE ASSEMBLY (29) - HYDROSTATIC DRIVE
№
Артикул
Название
Примечание
Количество
1
F8240
PLUG - upper port plate
1шт.
2
A27410
O-RING,0.487" ID x 0.693" OD x 0.103"
"O" RING - (3/32" x 1/2" I.D.) for plate plug
1шт.
3
NSS
NOT SOLD SEPARAT
"O" RING - (1/16" x 3/4" I.D. - 90 durometer) port plate
3шт.
4
F1290
BODY - port plate
1шт.
BOLT - 5/16" x 3-1/4" N.C. hex. (13-552) L.W. (92-5)
3шт.
5
F87195
LOCK VALVE
VALVE - relief assembly, for F1290 port plate
1шт.
F84831
SEAL
KIT - repair, port plate seal
1шт.
6
NSS
NOT SOLD SEPARAT
"O" RING - (3/32" x 3/4" I.D.)
1шт.
7
NSS
NOT SOLD SEPARAT
"O" RING - (3/32" x 5/8" I.D.)
1шт.
8
NSS
NOT SOLD SEPARAT
WASHER - (3/32" x 5/8" I.D.) backup - rubber
1шт.
9
F8242
PLUG - body
1шт.
10
NSS
NOT SOLD SEPARAT
"O" RING - (3/32" x 3/4" I.D.) body plug
1шт.
11
F8243
PLUNGER - lock-out
1шт.
12
NSS
NOT SOLD SEPARAT
"O" RING - (3/32" x 3/4" I.D.) spool
2шт.
13
F77045
BODY - with spool (Includes ref. 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22 and 23)
1шт.
14
F8235
WASHER
- (59/64" O.D.) backup
1шт.
15
F8224
SLEEVE
- spool
1шт.
16
F8225
SPRING - spool centering
1шт.
17
F8236
SHIM
WASHER - (51/64" O.D.) backup
1шт.
18
F77047
CAP
- spool
1шт.
19
F8237
RING
SNAP RING - (1/2" sq. clsd.) spool cap
1шт.
20
F8240
PLUG - lock-out spring
1шт.
21
A27410
O-RING,0.487" ID x 0.693" OD x 0.103"
"O" RING - (3/32" x 1/2" I.D.) for F8240 plug
1шт.
22
F8228
SPRING
- lock-out
1шт.
23
NSS
NOT SOLD SEPARAT
POPPET - relief
1шт.
24
F13237
PLATE - cover
1шт.
25
NSS
NOT SOLD SEPARAT
"O" RING - (1/16" x 3/4" I.D. - 90 durometer) for F13237
3шт.
26
NSS
NOT SOLD SEPARAT
"O" RING - (3/32" x 1-1/2" I.D.)
1шт.
27
F8223
PLATE - orifice
1шт.
28
F8245
RETAINER - orifice plate
1шт.
F84831
SEAL
KIT - repair, port plate seal (Includes ref. 6, 7, and 8)
1шт.
F84832
KIT - "O" ring - between sections (Includes ref. 3, 25, and 26)
1шт.
F84834
KIT
- repair, F77045 header section (Includes ref. 10, 12, 21 and 23)
1шт.
