Запчасти Case IH 1060 (08) - SPEED CONTROL LINKAGE (29) - HYDROSTATIC DRIVE

1

F14147

SHIELD - control (Used without cab)

1шт.

SCREW - 1/4" x 1/2" N.C. mach. (171-211) nut (25-104)

1шт.

2

F87815

BRACKET - control

1шт.

BOLT - 1/4" x 1-1/2" N.F. hex. (14-424) nut (25-114)

2шт.

BOLT - 3/8" x 1-1/2" N.F. hex. (14-624) nut (25-116)

3шт.

SCREW - 1/4" x 1/2" N.C. mach. (171-211)

3шт.

NUT - 1/4" N.C. Tinnerman (131-135)

3шт.

3

F14153

MOLDING - for grain bin (Without cab)

1шт.

4

A36509

KNOB - control

1шт.

ROLL PIN - 1/4 x 1/2" (138-127)

1шт.

5

F88261

LEVER - control

1шт.

G15947

BUSHING

1шт.

6

F87814

BRACKET - mounting

1шт.

7

F88138

CABLE - push-pull, pump

1шт.

8

F88140

TERMINAL - pump tube

1шт.

BOLT - 1/4" x 1-1/2" N.F. hex. (14-424) nut (25-114)

2шт.

9

F87816

BRACKET - shield

2шт.

SCREW - 1/4" x 1/2" N.C. mach. (171-211)

2шт.

BOLT - 1/4" x 1-1/2" N.F. hex. (14-424) nut (25-114)

2шт.

10

A35134

BEARING

EYE - pump and motor control

2шт.

NUT - 5/16" N.F. hex. jam

2шт.

11

G10786

DISC

- friction (Cork)

1шт.

12

G49412

WASHER

- spring

1шт.

13

195-533

WASHER,1/2", SAE

1шт.

14

425-138

SLOTTED NUT,1/2"-20, G8

NUT, SLOTTED, , Shear 1/2"-20, G8

1шт.

PIN - 3/32" x 7/8" cotter (132-27)

1шт.

15

F13328

SCREW

STOP

1шт.

16

F13329

WASHER

WASHER - nylon

1шт.

17

G15951

NUT

HAND NUT

1шт.

18

F14564

COVER - control shield

1шт.

SCREW - 1/4" x 1/2" N.C. mach (171-211) nut (25-104)

4шт.

19

F14146

SHIELD - control

1шт.

SCREW - 1/4" x 1/2" N.C. mach (171-211) nut (25-104)

1шт.

20

F88136

BRACKET - motor control cable

1шт.

BOLT - 1/4" x 1-1/2" N.F. hex. (14-424) nut (25-114)

2шт.

BOLT - 1/4" x 1-1/2" N.F. hex. (14-424) nut (25-114)

2шт.

21

F17860

CLIP - for motor cable

1шт.

22

F88137

CABLE - push-pull, motor

1шт.

23

F14151

HAND NUT - valve

1шт.

NUT - 3/8" N.C. jam (25-146)

1шт.

24

F40889

EYE - hook

1шт.

NUT - 5/16" N.C. jam (25-146)

2шт.

25

F87820

ROD - salvo, w/yoke

1шт.

26

F87819

VALVE - salvo

1шт.

WASHER - 3/16" flat (95-3)

3шт.

NUT - #12 - 24 N.C. hex. jam (129-670)

1шт.

27

218-1057

ELBOW,90 Degree, 7/8"-14, 37 Degree x 3/8"-18, NPTF

- 5/8" O.D. x 3/8" NPT

2шт.

28

F87818

HOSE - dump valve (Short)

1шт.

29

F87817

HOSE - dump valve (Long)

1шт.

30

F12441

CLAMP - hose

4шт.

BOLT - 5/16" x 1-3/4" rhd. sq. nk. (11-528) nut (25-105)

2шт.

31

F14152

ANCHOR - hose

1шт.

NUT - 5/16" N.C. hex (25-105) L.W. (92-5)

1шт.

NUT - 3/8" N.F. hex. (25-116) L.W. (92-6)

1шт.
