Запчасти Case IH 1060 (02) - OPERATORS PLATFORM (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

F87015

PLATFORM - operator's

1шт.

2

F87021

HAND RAIL - L.H. front

1шт.

3

F1213

LEVER - control, L.H.

1шт.

4

F1966

CAP - steering column

1шт.

5

F1211

LEVER - control, R.H.

1шт.

6

F87022

HAND RAIL - R.H. front

1шт.

7

F14571

PANEL - instrument

1шт.

8

F87018

CONSOLE - instrument panel

1шт.

9

F13077

SCREW

COVER - stringer

1шт.

10

F12464

STRINGER - inside operator's platform

1шт.

BOLT - 1/4 x 1/2" N. F. hex. (114-2) nut (129-121)

4шт.

BOLT- 1/4" x 5/8" N.F. hex. (114-3) nut (129-121)

1шт.

WASHER - 1/4" plain (195-518)

4шт.

BOLT - 1/4" x 5/8" rhd. sq nk. (111-102) nut (129-101)

4шт.

BOLT - 5/16" x 3/4" N.F. hex. (114-102) nut (129-122)

2шт.

11

F13309

SCREW

BRACKET - oil filter

1шт.

BOLT - 1/4" x 3/4" rhd sq. nk. (11-412) nut (25-104)

3шт.

12

F87238

PLATFORM - rear, operator's

1шт.

13

F13299

GROMMET - loop line

2шт.

14

F13300

ANGLE - grommet

4шт.

BOLT - 1/4" x 1" rhd. sq. nk. (11-416) nut (25-104) (See page 211 #A958 Parts Catalog)

4шт.

F87757

FRAME - main

1шт.
