Запчасти Case IH 1060 (28) - HEADER CONTROL (29) - HYDROSTATIC DRIVE

1

F87022

HANDRAIL - front, R.H.

1шт.

2

F1211

LEVER - control, R. H.

1шт.

3

F1078

JOINT

BLOCK - spacer, front handrail

1шт.

BOLT - 3/8" x 2" rhd. sw. nk. (11-632) nut (25-106)

2шт.

4

F1213

LEVER - control L. H.

1шт.

5

F87021

HANDRAIL - front, L. H.

1шт.

BOLT - 3/8" x 2" N.F. hex. (14-632) nut (25-116)

1шт.

6

F13030

ROD - control, upper

2шт.

NUT - 3/8" N.F. hex. jam (25-156)

2шт.

PIN - 1/8" x 3/4" cotter (132-46)

2шт.

7

213-4

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

CLEVIS - for ref. 6

2шт.

PIN - clevis (141-4)

2шт.

PIN - 3/32" x 3/4" cotter (132-26)

2шт.

8

F11948

BRACKET - pivot, bellcrank

2шт.

BOLT - 5/16" x 5/8" rhd. sq. nk. (11-510) nut (25-105)

4шт.

9

F11947

SHAFT - pivot, bellcrank

1шт.

PIN - 1/8" x 1-1/4" cotter (132-50)

2шт.

10

F1082

BELLCRANK

2шт.

11

O4413N

WASHER - for F11947 shaft, ref. 9

3шт.

12

213-4

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

CLEVIS - for ref. 15

1шт.

PIN - clevis (141-4)

1шт.

PIN - 3/32" x 3/4" cotter (132-26)

1шт.

13

14-640

BOLT,Hex, 3/8" - 24 x 2-1/2", Gr 5

- 3/8 " x 2-1/2" N.F. hex.

1шт.

14

25-156

JAM NUT,Jam, 3/8"-24, G5

- 3/8" N.F. hex. jam

2шт.

15

F11952

ROD - control, lower

1шт.

NUT - 3/8" N.F. hex. jam (25-156)

1шт.

16

141-4

CLEVIS PIN,3/8" x 1.060"

PIN, CLEVIS, 3/8" x 1.060"

1шт.

PIN - 3/32" x 3/4" cotter (132-26)

1шт.

17

F8167

BRACKET - mounting, control valve

2шт.

BOLT - 1/4" x 1/2" N.F. hex. (14-48) nut (25-114)

6шт.

18

K4475

SPACER - for control valve

1шт.

19

F87244

VALVE - control, header lift (Replaced by F87855 when stocks are exhausted)

1шт.

F87855

VALVE - control, header lift (Replaces F87244)

1шт.

BOLT - 3/8" x 2-1/4" N.C. hex. (13-636) L.W. (92-6)

1шт.

BOLT - 3/8" x 5/8" N.C. hex. (13-610) L.W. (92-6)

2шт.
