Запчасти Case IH 1060 (20) - RESERVOIR AND PUMP SHROUD (29) - HYDROSTATIC DRIVE

1

F13289

ROD - tension

2шт.

NUT - 3/8" N.C. hex. (25-106)

4шт.

2

F87226

PLATE - mount, left engine

1шт.

BOLT - 7/16" x 1" N.F. hex (14-716) nut (25-117)

4шт.

3

F87228

FIREWALL - engine

1шт.

BOLT - 5/16" x 1" N.F. hex. (14-516) nut (25-115)

4шт.

BOLT - 5/16" x 3/4" N.F. hex. (14-512) nut (25-115)

1шт.

4

F13306

SUPPORT - angle shroud

1шт.

BOLT - 5/16" x 3/4" N.F. hex. (14-512) nut (25-116)

2шт.

5

F13303

HOOD - pump shroud

1шт.

BOLT - 5/16" x 1" rhd. sq. nk. (11-516) nut (25-105)

2шт.

BOLT - 5/16" x 3/4" rhd. sq. nk. (11-512) nut (25-105)

4шт.

BOLT - 1/4" x 1" rhd. sq. nk. (111-111) nut (129-101)

2шт.

6

F13305

SCREW

ANGLE - cross, pump shroud

2шт.

7

F13324

SCREW

CLAMP - grille, upper

1шт.

BOLT - 1/4" x 3/4" N.F. hex. (114-5) nut (129-121)

3шт.

8

F13326

SCREW

GRILLE - pump shroud

1шт.

9

F13325

SCREW

CLAMP - grille, lower

1шт.

BOLT - 1/4" x 3/4" N.F. hex. (114-5) nut (129-121)

3шт.

10

F13323

SCREW

SHEET - rear

1шт.

NUT - 1/4" N.C. wing (129-409)

4шт.

WASHER - 1/4" (195-518) L.W. (192-19)

4шт.

11

F13321

SCREW

COVER - lower, pump shroud

1шт.

BOLT - 1/4" x 1/2" N.F. hex. (114-2) nut (129-121)

2шт.

12

F13320

COVER - upper, pump shroud

1шт.

BOLT - 1/4" x 1/2" N.F. hex. (114-2) nut (129-121)

3шт.

13

F87243

ANGLE - front, pump shroud

1шт.

BOLT - 1/4" x 1/2" rhd. sq. nk. (11-48) nut (25-104)

1шт.

BOLT - 5/16" x 3/4" rhd. sq. nk. (11-512) nut (25-105)

2шт.

14

F13304

CLAMP - oil reservoir

2шт.

15

F13302

PAD - oil reservoir

2шт.

16

F87242

RESERVOIR - oil, hydrostatic

1шт.

17

F88284

COVER - oil reservoir

1шт.

18

F5922

CAP

- oil reservoir

1шт.
