Запчасти Case IH 1060 (330[1]) - RADIATOR FRAME AND SCREEN (10) - ENGINE

1

F79847

AIR SCREEN - radiator

1шт.

2

F9318

ROD - hinge, radiator screen

1шт.

PIN - 1/8" x 3/4" cotter (132-46)

2шт.

3

F79444

STACK - radiator frame

1шт.

4

F86525

CLIP

- access door

2шт.

RIVET - 3/16" x 4/16" #2160 semi-tub steel (151-123)

2шт.

5

F8077

DOOR - access, radiator stack

1шт.

6

F9300

SEAL - felt, radiator mounting

2шт.

7

F6181

SPRING - air screen

4шт.
