Запчасти Case IH 1010 (350) - MODEL H-318 ENGINE, CYLINDER HEAD (10) - ENGINE

1

F1946

HEAD - cylinder

2шт.

F12924

BOLT - short, cylinder head (Not shown)

10шт.

F12925

BOLT - long, cylinder head (Not shown)

10шт.

2

F12922

GASKET - cylinder head

2шт.

3

F86917

COVER - L.H.

1шт.

114-122

BOLT,Hex, 5/16" - 24 x 2", Gr 5

and fl. wshr. (195-21) Hex, 5/16"-24 x 2", G5

1шт.

4

F12926

GASKET - cover

2шт.

5

F86916

COVER - R.H.

1шт.

114-122

BOLT,Hex, 5/16" - 24 x 2", Gr 5

and fl. wshr. (195-21) Hex, 5/16"-24 x 2", G5

1шт.

6

F21213

BREATHER CAP - (Replaces F86744 when stocks are exh.)

1шт.

F86744

BREATHER CAP - (Replaced by F21213 when stocks are exh.)

1шт.

7

F12662

DIPSTICK - oil level indicator

1шт.

8

F12663

TUBE - dipstick

1шт.

9

F85438

BLOCK - short, cylinder

1шт.

BLOCK - cylinder (Includes plugs, dowels, with oil pump and distributor drive shaft bushing)

1шт.

CRANKSHAFT - (Includes clutch shaft pilot bushing), cylinder block

1шт.

BEARING SETS - main (#1-2-3-4-5 upper and lower halves), cylinder block

5шт.

CAPS AND SCREWS - main bearing, cylinder block

5шт.

SET OF OIL SEALS - (#5 main bearing), cylinder block

1шт.

PISTONS W/PINS - (Includes inserts and retaining rings), cylinder block

8шт.

CONNECTING RODS - (Includes caps, nuts, screws and bushings), cylinder block

8шт.

RING SETS - (See F12886), cylinder block

8шт.

BEARING - camshaft (#1-2-3-4-5), cylinder block

5шт.

10

F86746

ALTERNATOR - with pulley (See page 362), cylinder block

1шт.

14-6168

BOLT - 3/8" x 4-1/4" N.F. hex., cylinder block

1шт.

230-4616

LOCK NUT,3/8"-24, GA

NUT - 3/8" Gripco, cylinder block

1шт.

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

and L.W. (92-5), cylinder block Hex, 5/16"-18 x 3/4", G5, Full Thd

1шт.

195-21

WASHER,5/16"

- flat, Cylinder block 5/16"

1шт.

F12667

STRAP - adjusting, alternator, cylinder block

1шт.

14-616

BOLT,Hex, 3/8" - 24 x 1", Gr 5

- 3/8" x 1" N.F. hex., nut (25-116) L.W. (92-6), cylinder block

1шт.

11

F12666

BRACKET - mounting, alternator, cylinder block

1шт.

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

and L.W. (92-6), cylinder block Hex, 3/8"-16 x 1 1/4", G5, Full Thd

2шт.

12

F86743

STARTING MOTOR - (See page 361), cylinder block

1шт.

13

F12874

SLINGER - oil, cylinder block

1шт.

14

F86911

PUMP - fuel, cylinder block

1шт.

15

F12664

GASKET, cylinder block

1шт.

13-622

BOLT,Hex, 3/8" - 16 x 1-3/8", Gr 5

- 3/8" x 1-3/8" N.C. hex. and L.W. (92-6), cylinder block

2шт.

16

F86923

COVER - chain case, cylinder block

1шт.

17

F12885

GASKET - cover, chain case, cylinder block

1шт.

17a

F87286

OIL SEAL ASSEMBLY - chain case cover, cylinder block

1шт.

18

F1935

PULLEY - fan drive, cylinder block

1шт.

19

F12671

WASHER - fan drive pulley, cylinder block

1шт.

20

14-1224

BOLT,Hex, 3/4" - 16 x 1-1/2", Gr 5

- 3/4" x 1-1/2" N.F. hex., cylinder block

1шт.

21

F86912

WATER PUMP - (See page 359), cylinder block

1шт.

22

F12904

GASKET, cylinder block

1шт.

23

F86888

INDICATOR - timing, cylinder block

1шт.

24

F1936

PULLEY - fan, cylinder block

1шт.

25

F1945

MANIFOLD - exhaust

2шт.

26

F12918

GASKET - exhaust manifold

2шт.

F12920

STUD

- exhaust manifold (Not shown)

16шт.

F12919

WASHER - manifold stud (Not shown)

16шт.

F12921

NUT - manifold stud (Not shown)

16шт.

27

F86955

MANIFOLD - intake

1шт.

114-201

BOLT,Hex, 3/8" - 24 x 1-1/4", Gr 5, Full Thd

- 3/8" x 1-1/4" N.F. hex.

8шт.

114-216

BOLT,Hex, 3/8" - 24 x 2", Gr 5

- 3/8" x 2" N.F. hex.

8шт.

113-213

BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5

2шт.

28

F86915

GASKET KIT - intake manifold

1шт.

F12914

SEALER - gasket, intake manifold (Not shown)

1шт.

29

F86750

CARBURETOR - (See page 364)

1шт.

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

and L.W. (92-5) Hex, 5/16"-18 x 1", G5, Full Thd

4шт.

222-619

ELBOW,90 Degree, 1/2"-24 x 1/8" NPT, Comp

- 5/16" O.D. x 1/8" NPT imp. #69F

1шт.

30

F12676

GASKET - carburetor

1шт.

31

F1943

ELBOW - water outlet, cylinder (See page 358)

1шт.

113-311

BOLT,Hex, 7/16" - 14 x 1-1/2", Gr 5

2шт.

32

F12673

HOSE - drain, oil pan

1шт.

221-525

CAP,1/2" NPT

- pipe 1/2" NPT

1шт.

33

F86895

OIL PAN - front drain

1шт.

F86885

SCREW - oil pan attaching, w/washer (Not shown)

18шт.

34

F87065

GASKET

KIT - oil pan

1шт.

35

F86897

PIPE AND STRAINER - suction

1шт.

36

F86969

OIL PUMP

1шт.

F13190

SPRING - relief valve, oil pressure (Not shown)

1шт.

37

A37189

FILTER, ELEMENT

FILTER - oil (Replaces G45210 when stocks are exhausted)

1шт.

G45210

FILTER, ELEMENT

FILTER - oil (Replaced by A37189 when stocks are exhausted)

1шт.

38

F12678

PLATE - oil filter adapter

1шт.

39

F12680

GASKET

1шт.

40

F12677

ADAPTER - oil filter to cylinder block

1шт.

F86919

GASKET KIT - engine

1шт.

NSS

NOT SOLD SEPARAT

GASKET - cylinder head

2шт.

F12926

GASKET - cover, cylinder head

2шт.

F12885

GASKET - cover, chain case

1шт.

F12911

GASKET - water outlet, cylinder elbow

1шт.

F87065

GASKET

KIT - oil pan

1шт.

NSS

NOT SOLD SEPARAT

GASKET - end, oil pan

2шт.

F12904

GASKET - water pump body

1шт.

F12664

GASKET - flange, fuel pump

1шт.

F12701

GASKET - flange, exhaust pipe

2шт.

F12900

GASKET - ignition distributor

1шт.

NSS

NOT SOLD SEPARAT

GASKET - intake manifold

2шт.

NSS

NOT SOLD SEPARAT

GASKET - intake manifold, front

1шт.

NSS

NOT SOLD SEPARAT

GASKET - intake manifold, rear

1шт.
