Запчасти Case IH 1010 (248) - HEADER LIFT AND VARIABLE SPEED CONTROL LINKAGE (35) - HYDRAULIC SYSTEMS

1

F79383

HANDRAIL - front R.H. (Grain bin combines)

1шт.

F79427

HANDRAIL - front R.H. (Bagger combines)

1шт.

2

F1211

LEVER - R.H. control

1шт.

3

F1078

JOINT

BLOCK - spacer, front handrail

1шт.

11-632

BOLT,Short NK, 3/8"-16 x 2", G2

- 3/8" x 2" rhd. sq. nk. and nut (25-106)

2шт.

4

F1213

LEVER - L.H. control

1шт.

5

F86090

HANDRAIL - front L.H. (See operator's platform)

1шт.

6

F8149

ROD - upper control

2шт.

132-46

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

2шт.

7

F11948

BRACKET - pivot, bellcrank

2шт.

11-510

SCREW,Short Nk, 5/16" - 18 x 5/8", Gr 2

BOLT - 5/16" x 5/8" rhd. sq. nk. and nut (25-105)

4шт.

8

F11947

SHAFT - pivot, bellcrank

1шт.

132-50

COTTER PIN,1/8" x 1 1/4"

Pin, Split (Cotter), 1/8" x 1 1/4"

2шт.

9

213-4

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

CLEVIS - upper and lower control rods (Both ends of bellcrank)

4шт.

10

F1082

BELLCRANK

2шт.

11

O4413N

WASHER - pivot shaft

3шт.

12

F10117

COLLAR

1шт.

14-416

SCREW,Hex, 1/4" - 28 x 1", Gr 5

BOLT, Hex, 1/4"-28 x 1, G5, Full Thd, and jam nut (25-154)

1шт.

13

230EB

SPRING

1шт.

14

F10910

CLAMP - V.S. clutch toggle arm

1шт.

15

F10909

ARM - toggle, V.S. clutch

1шт.

411-48

CARRIAGE BOLT,Sq Nk, 1/4" - 20 x 1/2", Gr 2

BOLT - 1/4" x 1/2" rhd. sq. nk. and nut (25-104)

3шт.

16

F11952

ROD - lower control

2шт.

25-156

JAM NUT,Jam, 3/8"-24, G5

- 3/8" N.F. hex. jam

2шт.

95-8

WASHER,1/2"

flat 1/2"

1шт.

17

141-4

CLEVIS PIN,3/8" x 1.060"

PIN, CLEVIS, 3/8" x 1.060"

4шт.

132-26

COTTER PIN

Pin, Split (Cotter), 3/32" x 3/4"

4шт.

18

F8167

BRACKET - mounting, control valve

2шт.

19

F87262

VALVE

- hydraulic, variable speed control (Replaces F86223 when stocks are exhausted)

1шт.

F86223

VALVE - hydraulic, variable speed control (Replaced by F87262 when stocks are exhausted)

1шт.

F9629

GROMMET - rubber (Not shown)

2шт.
