Запчасти Case IH 815 (06-05) - COOLING, COOLANT FILTER-CONDITIONER Cooling

121897C92

FILTER

PARTS ACCESSORY, coolant filter, conditioner, consists of ref. nos. 1 thru 11 and (1) adapter 115224, (1) clamp 308576R1, (1) gasket 675384C1, (1) plug 444660, (1) instruction manual

1шт.

1

121881C1

BRACKET

ASSY, water filter

1шт.

2

SA2172

SPACER,3/8" Pipe x 1/2"

3/8 x 1/2 std pipe

2шт.

24884R1

SCREW,Hex, 3/4"-10 x 1", G8

BOLT, 3/4 x 1 PHC type 8

1шт.

3

427446C1

HEAD

BASE, water filter

1шт.

179841

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

3/8-16 x 1-1/4 pln type 5

1шт.

4

690171C1

FILTER

ELEMENT, water filter

1шт.

5

444150

TEE,3/8"-18 NPTF Fem x 3/8"-18 NPTF Male Run

3/8-18 brass auto pipe

1шт.

6

121894C1

FAUCET,3/8" - 18 NPTF x 5/8" - 24

VALVE, shut-off

2шт.

7

606618C1

ELBOW UNION

ELBOW, water filter base

1шт.

8

121750C1

ELBOW

oil cooler

1шт.

9

TUBE, water inlet, use 23.1 in. of 3/8 OD tubing from 50 ft. roll marked 995053R1 plus one nut 137399 and one nut 265205 and one sleeve 265204R1

1шт.

10

362120R1

CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type

CLIP, water inlet tube hold-down

1шт.

64889C1

CABLE SHEATH

CONDUIT, convoluted insulated

1шт.

11

TUBE, water outlet, use 14 in. of 3/8 OD tubing from a 50 ft. roll marked 995063R1 plus 2 nuts 265205R1 and 2 sleeves 265204R1

1шт.
