Артикул
Название
Примечание
Количество
1
282543R91
OIL SEAL
brake housing dirt
2шт.
1
380637R91
SEAL,44.45mm ID x 66.72mm OD x 5.08mm Thk
brake housing dirt, heavy duty
2шт.
2
566206R2
BOLT,5/8" - 18 x 2.38", Class 8
5/8-18 x 2-3/8 in. long wheel
16шт.
2
379510R2
BOLT,5/8" - 18 x 3 1/16"
5/8-18 x 3-1/16 in. long wheel, heavy duty
16шт.
364450R1
SPECIAL NUT
NUT, wheel bolt
16шт.
2
174280C91
PACKAGE
main wheel stud, consists of, (1) stud 174197C1 (NSS), (1) nut 274639
1шт.
3
385945R1
SHAFT
final drive
2шт.
3
404070R1
SHAFT, final drive, heavy duty
2шт.
4
380185R91
OIL SEAL
SEAL, final drive outer brg cage oil
2шт.
4
404489R91
OIL SEAL,83.57mm ID x 127.1mm OD x 11.89mm Thk
final drive outer brg cage oil, heavy duty
2шт.
5
ST2073
TAPERED BEARING,2.625" ID x 4.4375" OD x 1.1875"
BEARING ASSY, final drive shaft outer cone
2шт.
5
ST2157
TAPERED BEARING,3.035" ID x 4.8126" OD x 1.3"
BEARING ASSY, final drive shaft outer cone, heavy duty
2шт.
6
13363D
TAPERED BEARING
BEARING, final drive shaft outer cup
2шт.
6
ST985
CUP
BEARING, final drive shaft outer cup, heavy duty
2шт.
7
395674R1
RETAINER, final drive outer bearing
2шт.
7
404077R1
RETAINER, final drive outer bearing, heavy duty
2шт.
179860
BOLT,Hex, 7/16" - 14 x 1 1/4", Gr 5
SCREW, 7/16-14 x 1-1/4 hex-hd cap
12шт.
103322
LOCK WASHER,7/16"
WASHER, LOCK, 7/16"
12шт.
8
606922C1
O-RING,0.139" Thk x 5.734" ID, -256, Cl 5, 75 Duro
5-3/4 x 6 x 1/8, final drive housing
1шт.
9
380282R1
SPACER, final drive shaft outer
2шт.
9
404071R1
BUSHING
SPACER, final drive shaft outer, heavy duty
2шт.
10
379504R11
GEAR
ASSY, final drive
2шт.
10
384101R91
GEAR ASSY, final drive, heavy duty
2шт.
373109R1
RIVET, final drive gear
12шт.
11
379505R1
SPACER
final drive gear inner
2шт.
11
404074R1
SPACER
SPACER, final drive gear inner, heavy duty
2шт.
12
583237R1
CAGE, final drive inner bearing
2шт.
12
404075R1
CAGE, final drive inner bearing, heavy duty
2шт.
297330R1
BOLT
SCREW, 3/8-16 x 1 hex-hd cap
8шт.
13
ST987
BEARING CUP
BEARING, final drive shaft inner cup
2шт.
13
ST863
BEARING CUP,93.22mm OD x 23.81mm W
BEARING, final drive shaft inner cup, heavy duty
2шт.
14
ST2118
TAPERED BEARING,1.75" ID x 3.27" OD x 0.9375"
BEARING ASSY, final drive shaft inner cone
2шт.
14
ST2122
BEARING ASSY,52.39mm ID x 30.16mm W
final drive shaft inner cone, heavy duty
2шт.
15
589765R1
WASHER
final drive shaft
2шт.
15
404076R1
WASHER
final drive shaft, heavy duty
2шт.
16
73177R1
NUT
final drive shaft
2шт.
16
404076R1
WASHER
NUT, final drive shaft, heavy duty
2шт.
103391
COTTER PIN,1/8" x 2 1/2"
Pin, Split (Cotter), 1/8" x 2 1/2"
2шт.
17
444592
PLUG,Sq Hd, 1/4"-14 NPTF
3/4-14 auto. sq-hd pipe
4шт.
18
587078R91
PAN ASSY.
PAN ASSY, final drive housing
2шт.
179837
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
24шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
24шт.
19
587655R1
GASKET
final drive housing pan
2шт.
20
379500R1
HOUSING, final drive LH
1шт.
20
379501R1
HOUSING, final drive RH
1шт.
21
110891H
BREATHER,1/8"-27 NPT, Short, w/washer
final drive housing oil, replaces 61991R91
2шт.
22
404158R1
CAP
final drive shaft
2шт.
23
AXLE ASSY, transmission, refer to main axle listing, this group
1шт.
24
618024R1
BEARING CUP,65.113mm OD x 13.97mm W
Final drive pinion shaft outer
2шт.
25
618023R91
BEARING ASSY,34.93mm ID x 18.2mm W
BEARING ASSY, final drive pinion shaft outer cone
2шт.
26
376461R2
SHAFT
final drive pinion, 13 teeth
2шт.
27
56934D
ROLLER BEARING,2.1663" ID x 3.8125" OD x 0.8268"
ASSY, final drive pinion shaft inner cone
2шт.
28
105497H
BEARING CUP,96.85mm OD x 15.77mm W
BEARING, final drive pinion shaft inner cup
2шт.
29
380186R92
OIL SEAL
brake adapter oil
2шт.
30
O-RING, 3-5/8 x 3-7/8 x 1/8, brake adapter
2шт.
31
376467R1
SHIM
brake adapter .007
1шт.
31
405627R1
SHIM
brake adapter .003
1шт.
32
379506R1
ADAPTER, brake
2шт.
141279
DOWEL,1/2" x 3/4"
PIN, 1/2 x 3/4 dowel
2шт.
376814R1
BOLT,Hex, 7/16" - 14 x 1 1/8", Gr 5, W/ Nylon Pellet
SCREW, 7/16 x 1-1/8 nylok hex-hd cap
10шт.
33
354627R1
SPRING
part of brake, 574966R92
4шт.
33
619731C1
SPRING
heavy duty, part of brake, 321163R91
6шт.
34
16028R1
BALL
7/8 diameter chrome steel, 10 used for heavy duty
8шт.
35
354642R1
STUD
actuating disc
4шт.
114493
JAM NUT,Jam, 5/16"-24, G5
4шт.
36
354640R91
LINK
actuating yoke, part of brake, 574966R92
2шт.
36
357114R91
LINK
actuating yoke, heavy duty, part of brake, 321163R91
2шт.
37
354641R1
LINK
actuating plain, part of brake, 574966R92
2шт.
37
357113R1
LINK
actuating plain, heavy duty, part of brake, 321163R91
2шт.
38
368293R91
PLATE
DISC ASSY, actuating, part of brake, 574966R92
2шт.
38
366182R92
BRAKE DISC
DISC ASSY, actuating, heavy duty, part of brake, 321163R91
2шт.
39
567989R92
DISC
ASSY, middle, part of brake, 574966R92
4шт.
39
321162R91
DISC
ASSY, middle, heavy duty, part of brake, 321163R91
4шт.
40
574966R92
BRAKE ASSY, wheel, 6 in.
2шт.
40
321163R91
BRAKE ASSY, wheel, heavy duty
2шт.
41
357043R1
CLEVIS,3/8" - 24
YOKE, brake operating
2шт.
16618R1
CLEVIS PIN,7/16" x 1.190"
PIN, 7/16 x 1-15/16 drilled
2шт.
107762
WASHER,3/32" x 5/8"
PIN, SPLIT, (COTTER), 3/32" x 5/8"
2шт.
42
381699R1
BOOT
wheel brake
2шт.
43
368296R3
CASE
HOUSING, wheel brake
2шт.
NLS
NO LONGER SERVICED
7/16-14 hex.
10шт.
179871
BOLT,Hex, 7/16" - 14 x 3 1/4", Gr 5
SCREW, 7/16-14 x 3-1/4 hex-hd cap
10шт.
PO10535
WASHER
17/32 x 1-1/4 x 11 ga
12шт.
44
379508R1
CAGE, brake housing dirt seal, used only w/housing, 368296R3
2шт.
403876R91
1шт.
PARTS ACCESSORY, heavy duty final drive, consists of, (1) bearing ST985, (1) bearing assy ST2157, (8) bolt 566206R2, (1) cage 404077R1, (1) instruction 1083724R1 (NSS), (1) nut 528935R1, (1) O-ring 606922C1, (1) pin 103391, (1) retainer 404075R1, (1) seal 404489R91, (1) shaft 404070R1, (1) spacer 404071R1, (1) spacer 404074R1, (1) washer 404076R1
1шт.
Выбрано товаров: 86
