Запчасти Case IH 503 (064) - SEPARATOR, HOOD AND SERVICE LADDER (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

628332R1

BLOCK

RETAINER, feeder pivot shaft

2шт.

2

628846R1

PIN, feeder pivot bracket

2шт.

520175R1

CLIP

QUICK ATTACHABLE COTTER

2шт.

3

340340R1

BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 8

feeder pivot bracket

8шт.

1/2 NUT

4шт.

482253

NUT, 1/2 flange whiz lock

2шт.

1/2 JAM NUT

2шт.

1/2 LOCK WASHER

8шт.

PO10535

WASHER

17/32 X 1-1/4 X 11 GA WASHER

4шт.

4

628331R91

BRACKET W/BOLT, feeder pivot RH, Not for use with windrow special

1шт.

4

634200R91

BRACKET W/BOLT, feeder pivot RH, For use with windrow special

1шт.

5/8 NUT

2шт.

575810R1

WASHER

21/32 X 1-1/2 X 11 GA WASHER

2шт.

5

565536R1

SUPPORT

SEAL, feeder pivot plate RH

1шт.

6

654320R1

REINFORCEMENT, front post RH

1шт.

3/8 X 3/4 CRG BOLT W/NUT

2шт.

1/2 X 1 MACH BOLT W/NUT

1шт.

3/8 LOCK WASHER

2шт.

1/2 LOCK WASHER

1шт.

7

628323R91

BRACKET W/GUSSET, feeder pivot LH

1шт.

8

565535R1

SUPPORT

SEAL, feeder pivot plate LH

1шт.

9

654319R1

REINFORCEMENT, separator front post LH, Serial no. 951 and above

1шт.

3/8 X 3/4 CRG BOLT W/NUT

2шт.

1/2 X 1 MACH BOLT W/NUT

1шт.

3/8 LOCK WASHER

1шт.

1/2 LOCK WASHER

1шт.

10

628001R91

BRACE W/PAD, Serial Range: separator-axle

1шт.

1/4 X 1-3/4 MACH BOLT

1шт.

1/2 X 1-1/4 CRG BOLT W/NUT

3шт.

1/2 X 1 MACH BOLT W/NUT

2шт.

1/2 X 1-1/4 MACH BOLT W/NUT

2шт.

1/4 CD-PLTD WING NUT

1шт.

5/8 X 1-1/4 CAP SCREW

2шт.

1/2 LOCK WASHER

2шт.

5/8 LOCK WASHER

2шт.

115551

LOCK WASHER,Int Tooth, 1/2"

WASHER, LOCK, , Not for use with track Int Tooth, 1/2"

4шт.

11

633325R1

GUSSET, separator to axle brace, For tracks

1шт.

11

631650R91

GUSSET W/PLATE, separator to axle brace, Not tracks

1шт.

7/16 X 1 CRG BOLT W/NUT

2шт.

7/16 X 1-1/2 MACH BOLT W/NUT

2шт.

7/16 X 1 NO. 3 PLOW BOLT

1шт.

7/16 LOCK WASHER

5шт.

12

NOT USED

1шт.

13

633639R1

BRACE, separator to axle gusset

1шт.

7/16 NUT

1шт.

7/16 X 1-1/4 CAP SCREW

1шт.

7/16 LOCK WASHER

1шт.

14

629844R1

EXTENSION, separator top

1шт.

5/16 X 3/4 CRG BOLT W/NUT

2шт.

118832

DRIVE BUSHING

NO. 10 X 1/2 SLT-RD-HD SELF-TAPPING SCREW

5шт.

5/16 LOCK WASHER

2шт.

15

582607R91

DOOR W/STIFFENER, separator top

1шт.

16

634388R1

HAND RAIL, service ladder

1шт.

5/16 X 1-1/2 MACH BOLT W/NUT

4шт.

5/16 LOCK WASHER

4шт.

17

627262R91

HOOD ASSY, separator, Serial no. 2430 and below

1шт.

17

938039R91

HOOD ASSY, separator, Serial no. 2431 and above, Not for straw chopper

1шт.

5/16 X 3/4 CAP SCREW

1шт.

5/16 X 1 CAP SCREW

1шт.

3/8 X 1/2 MACH BOLT W/NUT

1шт.

5/16 NUT

1шт.

5/16 LOCK WASHER

1шт.

3/8 LOCK WASHER

1шт.

Q397

WASHER

11/32 X 3/4 X 16 GA WASHER

1шт.

18

631202R91

TIE W/PAD, separator rear cross

1шт.

19

629776R1

BRACKET, tool box, For machines equipped with L.P. gas engines

2шт.

1/4 X 3/4 CRG BOLT W/NUT

4шт.

3/8 X 3/4 CRG BOLT W/NUT

4шт.

1/4 LOCK WASHER

4шт.

3/8 LOCK WASHER

4шт.

20

629769R1

TOP, tool box

1шт.

1/8 X 3/4 COTTER PIN

2шт.

557109R1

WASHER

17/64 X 1/2 X 16 GA WASHER

4шт.

21

629767R91

BOX W/TOP, tool

1шт.

1/4 X 1-1/4 MACH BOLT W/NUT

3шт.

1/4 X 1-3/4 MACH BOLT

1шт.

1/4 CD-PLTD WING NUT

1шт.

1/4 LOCK WASHER

4шт.

136661H

WASHER

17/64 X 1 X 16 GA WASHER

4шт.

22

628588R91

LADDER W/SIDE SERVICE

1шт.

3/8 X 1-1/4 MACH BOLT W/NUT

2шт.

3/8 LOCK WASHER

2шт.

23

565449R1

CLIP

straw rack inspection door

16шт.

5/16 X 1 CRG BOLT W/NUT

16шт.

935736R1

NUT, WING

5/16 WING NUT

16шт.

5/16 LOCK WASHER

16шт.

24

568807R1

DOOR, straw rack inspection

2шт.

25

633500R91

CAB ASSY, separator, Gasoline, diesel and windrow special, Not hydrostatic ground drive, Serial no. 2430 and below

1шт.

25

633637R91

CAB ASSY, separator, LP gas, Serial no. 2430 and below

1шт.

25

150015C91

CAB ASSY, separator, LP gas, Not hydrostatic ground drive, Serial no. 2431 and above

1шт.

25

938752R91

CAB ASSY, separator, Gasoline, diesel, and windrow special, Not hydrostatic ground drive, Serial no. 2431 and above

1шт.

25

150762C91

BODY ASSY, separator, Gasoline, diesel, windrow special and tracks, For hydrostatic ground drive, Serial no. 3055 through 3072 and 3251 and above

1шт.

25

150764C91

BODY ASSY, separator, LP gas, For hydrostatic ground drive, Serial no. 3055 throught 3072 and 3251 and above

1шт.

5/16 X 1 CRG BOLT W/NUT

1шт.

3/8 X 3/4 CRG BOLT W/NUT

1шт.

7/16 X 1 CRG BOLT W/NUT

1шт.

1/2 X 1-1/2 CRG BOLT W/NUT

1шт.

1/2 X 1-1/2 CRG BOLT W/NUT

1шт.

3/8 X 1/2 MACH BOLT W/NUT

1шт.

3/8 X 1-1/4 MACH BOLT W/NUT

1шт.

3/8 X 1-3/4 MACH BOLT W/NUT

1шт.

3/8 X 4-3/4 MACH BOLT W/NUT

1шт.

1/2 X 1 MACH BOLT W/NUT

1шт.

1/2 X 1-1/2 MACH BOLT W/NUT

1шт.

1/2 X 2-3/4 MACH BOLT W/NUT

1шт.

5/8 X 1-1/2 MACH BOLT W/NUT

1шт.

3/4 X 1-3/4 MACH BOLT W/NUT

1шт.

1/4 NUT

1шт.

5/16 NUT

1шт.

3/8 NUT

1шт.

7/16 NUT

1шт.

1/2 NUT

1шт.

5/8 NUT

1шт.

935763R1

5/16 WING NUT

1шт.

9413944

NUT

5/8 STOVER LOCK NUT

1шт.

3/16 X 1 COTTER PIN

1шт.

1/8 X 3/4 COTTER PIN

1шт.

5/16 X 3 DLD PIN

1шт.

1/2 X 2 DLD PIN

1шт.

1/4 X 3/4 CAP SCREW

1шт.

1/4 X 3/8 CAP SCREW

1шт.

1/4 X 1-1/2 CAP SCREW

1шт.

1/4 X 3-1/4 CAP SCREW

1шт.

1/4 X 3/8 SLTD-RD-HD MACH SCREW

1шт.

7/16 X 5 CAP SCREW

1шт.

1/2 X 1-1/4 CAP SCREW

1шт.

364257R1

BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 8

1/2 X 1-1/2 CAP SCREW

1шт.

1/2 X 1-3/4 CAP SCREW

1шт.

1/2 X 2 CAP SCREW

1шт.

5/8 X 1-1/2 CAP SCREW

1шт.

161068R1

BOLT,Spcl, Hex, 5/8" - 11 x 1 1/2"

5/8 X 1-3/4 CAP SCREW

1шт.

5/8 X 2 CAP SCREW

1шт.

5/16 X 1 HEX-HD SELF TAPPING SCREW

1шт.

1/4 LOCK WASHER

1шт.

5/16 LOCK WASHER

1шт.

7/16 LOCK WASHER

1шт.

3/8 LOCK WASHER

1шт.

1/2 LOCK WASHER

1шт.

5/8 LOCK WASHER

1шт.

115554

LOCK WASHER,Int Tooth, 3/4"

3/4 INTERNAL TOOTH LOCK WASHER

1шт.

11/32 X 3/4 X 16 GA WASHER

1шт.

13/32 X 3/4 X 16 GA WASHER

1шт.

17/32 X 1 X 11 GA WASHER

1шт.

38971H

17/32 X 1-3/4 X 11 GA WASHER

1шт.

551177R1

WASHER

21/32 X 1-1/4 X 16 GA WASHER

1шт.

575810R1

WASHER

21/32 X 1-1/2 X 11 GA WASHER

1шт.

26

633518R1

DOOR

concave inspection

4шт.

27

633513R91

DOOR W/GUIDE, cylinder LH

1шт.

27

633514R91

DOOR W/GUIDE, cylinder RH

1шт.

3/8 X 1/2 CRG BOLT W/NUT

2шт.

7/16 X 1 CRG BOLT W/NUT

1шт.

7/16 X 1-3/4 CRG BOLT W/NUT

1шт.

1/2 NUT

4шт.

3/8 LOCK WASHER

2шт.

7/16 LOCK WASHER

21шт.

1/2 LOCK WASHER

2шт.

28

569623R1

CLAMP

CLIP, cylinder door support LH

1шт.

1/4 X 1 SLT-RD-HD MACH SCREW

2шт.

1/4 NUT

2шт.

1/4 LOCK WASHER

2шт.

557109R1

WASHER

17/64 X 1/2 X 16 GA WASHER

2шт.

29

627705R91

RETAINER W/STUD, cylinder front door LH, Not for use with windrow special

1шт.

5/16 X 1 MACH BOLT

3шт.

5/16 LOCK WASHER

3шт.

30

582564R1

SEAL

cylinder door, Not windrow special

1шт.

31

582565R1

STRIP cylinder door seal, Not windrow special

1шт.

32

627706R91

SUPPORT

RETAINER W/STUD, cylinder front door RH, Not for use with windrow special

1шт.

5/16 X 1 MACH BOLT

3шт.

5/16 LOCK WASHER

3шт.

33

569624R1

CLAMP

CLIP, cylinder door support RH

1шт.

1/4 NUT

2шт.

1/4 X 1 XLT-RD-HD MACH SCREW

2шт.

1/4 LOCK WASHER

2шт.

557109R1

WASHER

17/64 X 1/2 X 16 GA WASHER

2шт.

34

569362R1

HANDLE, cylinder door

2шт.

35

627915R91

DOOR W/STIFFENER, cylinder front, Not for use with windrow special

1шт.

1/4 X 1 SLT-RD-HD MACH SCREW

7шт.

1/4 LOCK WASHER

7шт.

36

654045R1

SHIM, separator hood tie bracket

4шт.

37

634553R91

RETAINER W/STUD, cylinder front door LH, For use with windrow special

1шт.

5/16 X 3/4 MACH BOLT

2шт.

5/16 LOCK WASHER

2шт.

38

634549R91

DOOR W/STIFFENER, cylinder front, For use with windrow special

1шт.

39

634554R91

RETAINER W/STUD, cylinder front door RH, For use with windrow special

1шт.

5/16 X 3/4 MACH BOLT

2шт.

5/16 LOCK WASHER

2шт.

40

219-8

LUBE NIPPLE,1/4" - 28 NPTF

FITTING, 1/4 straight lubrication

1шт.

41

NOT USED

1шт.

42

NOT USED

1шт.

43

161249C1

ANGLE, separator top reinf., special

2шт.

18764R1

HARDWARE,Hex, 5/16"-18 x 3/4", G2

BOLT, 5/16 x 3/4 C-Z hex hd mach

16шт.

120376

NUT,5/16"-18, G5

16шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

16шт.
