Запчасти Case IH 503 (093) - FAN DRIVE AND SLOW SPEED FAN DRIVE ATT (74) - CLEANING

1

629164R2

SPROCKET ASSY.

SPROCKET AND SHEAVE, elevator jackshaft drive 38-t

1шт.

151629R1

BOLT,Hex, 3/8" - 16 x 1", Gr 8, Full Thd

3/8 X 1 CAP SCREW

3шт.

3/8 LOCK WASHER

3шт.

2

163446C1

KEY

3/8 x 2-1/2 straight

1шт.

3

629718R2

HUB CAP

HUB, fan and straw rack drive sheave

1шт.

4

937928R1

V-BELT

Fan and straw rack drive

1шт.

5

568237R11

SHEAVE W/SPACER, straw rack driven, regular, Not bean special

1шт.

6

577715R1

SPACER,16.69mm ID x 22.23mm OD x 10.32mm L

fan belt tightener sheave bolt

2шт.

7

631487R1

YOKE, fan drive belt tightener sheave

1шт.

8

631528R1

DRAW BOLT, belt tightener

1шт.

1/2 C-Z NUT

2шт.

3/16 X 1 COTTER PIN

1шт.

115551

LOCK WASHER,Int Tooth, 1/2"

WASHER, LOCK, Int Tooth, 1/2"

1шт.

17/32 X 1 X 16 GA WASHER

1шт.

9

629629R91

ARM W/PIVOT, drive belt tightener

1шт.

10

627402R1

BRACKET, fan and straw rack drive tightener pivot shaft

1шт.

3/8 X 1 CRG BOLT W/NUT

2шт.

3/8 LOCK WASHER

2шт.

11

631141R1

SHAFT, drive belt tightener pivot

1шт.

1-1/32 X 1-1/2 X 16 GA WASHER

1шт.

576517R1

LOCK PIN,1/4" x 1 1/2", Slotted

Pin, 1/4" x 1 1/2", Slotted

1шт.

12

634077R1

PULLEY

SHEAVE, inner half driven, regular, Not windrow special

1шт.

12

634079R1

SHEAVE, inner half driven, Regular for windrow special, special, 504 to 611 rpm

1шт.

12

153052C1

PULLEY, inner half driven, Special 404 to 470 rpm

1шт.

13

Q81

KEY,Gib, 3/8" Sq x 1 3/4"

3/8 x 3/8 x 1-3/4 gib

1шт.

14

564481R2

SHEAVE, outer half driven, regular, Not windrow special

1шт.

14

569811R2

SHEAVE, outer half driven, Regular for windrow special, special, 504 to 611 rpm

1шт.

14

153053C1

PULLEY, outer half driven, special, 404 to 470 rpm

1шт.

236481R1

BOLT,Hex, 3/8" - 16 x 1 1/8", Gr 8

3/8 X 1-1/8 C-Z CAP SCREW

3шт.

Q1505

WASHER

13/32 X 1 X 16 GA WASHER

3шт.

15

582626R1

HUB, driven sheave

1шт.

16

475954R1

NUT

3/8 C-Z flange whiz lock

3шт.

17

Q3930

KEY,Gib, 5/16" Sq x 1 3/4"

5/16 x 5/16 x 1-3/4 gib

1шт.

18

574097R91

PULLEY

SHEAVE ASSY, fan belt tightener

1шт.

5/8 X 3-1/2 CAP SCREW

1шт.

5/8 NUT

1шт.

5/8 LOCK WASHER

1шт.

551177R1

WASHER

21/32 X 1-1/4 X 16 GA WASHER

5шт.
