Запчасти Case IH 503 (321) - GUIDE (48) - TRACKS & TRACK SUSPENSION

Схема запчастей Case IH 503 - (321) - GUIDE (48) - TRACKS & TRACK SUSPENSION
4
2
3
3
5
6
1
2
7

Артикул

Название

Примечание

Количество

1

654665R91

SPINDLE W/BUSHING ASSY, guide wheel LH, Includes ref no. 2

1шт.

70120D

SLOTTED NUT,7/8"-14

7/8-14UNF SLT JAM NUT

1шт.

2

574294R1

BUSHING

spindle

4шт.

3

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

2шт.

4

631663R91

AXLE W/BUSHING, guide wheel, Includes ref no. 5

1шт.

5

575789R1

BUSHING

axle pivot tube

2шт.

6

219-8

LUBE NIPPLE,1/4" - 28 NPTF

FITTING, 1/8 straight lubrication

1шт.

7

155796C91

KNUCKLE ASSY, guide wheel right, Includes ref no. 2

1шт.

70120D

SLOTTED NUT,7/8"-14

7/8-14UNF SLT JAM NUT

1шт.

Выбрано товаров: 9
