Запчасти Case IH 303 (099) - OPERATORS LEVER SHROUD, SERIAL NO. 7278 AND ABOVE (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

938850R1

SUPPORT, operators control LH housing

1шт.

14995R1

BOLT

3/8 x 3/4 crg bolt w/nut

3шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

3/8 x 1 crg bolt w/nut

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

2

938851R1

SUPPORT, operators control housing RH

1шт.

14995R1

BOLT

3/8 x 3/4 crg bolt w/nut

3шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

3шт.

Q1505

WASHER

13/32 x 1 x 16 ga washer

1шт.

3

938832R91

SUPPORT ASSY, operators ocntrol housing

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

3/8 x 1 crg bolt w/nut

4шт.

18779R1

BOLT,Hex, 3/8"-16 x 1 1/2", Gr 2

3/8 x 1-1/2 C-Z mach bolt w/nut

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

4

938852R1

SIDE, operators control housing LH

1шт.

264-1478

SELF-TAP SCREW,Slotted Pan Hd, 1/4" x 1/2"

1/4 x 1/2 pan-hd self-tapping screw

10шт.

5

938853R1

SIDE, operators control housing RH

1шт.

264-1478

SELF-TAP SCREW,Slotted Pan Hd, 1/4" x 1/2"

1/4 x 1/2 pan-hd self tapping screw

7шт.

6

938854R91

PANEL ASSY, operators instrument

1шт.

14994R1

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2

BOLT, CARRIAGE, , w/Nut Short NK, 5/16"-18 x 3/4", G2

2шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

Q397

WASHER

11/32 x 3/4 x 16 ga washer

2шт.

7

938857R1

SUPPORT, operators instrument gauge

1шт.

264-1478

SELF-TAP SCREW,Slotted Pan Hd, 1/4" x 1/2"

1/4 x 1/2 pan-hd self tapping screw

4шт.
