Запчасти Case IH 303 (245) - CONDENSER AND COMPRESSOR, SERIAL NO. 11554 AND ABOVE (50) - CAB CLIMATE CONTROL

1

634305R1

ELBOW, muffler

1шт.

2

31790C1

CLAMP, muffler

1шт.

18495R1

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2

3/8 x 1-1/4 C-Z hex-hd mach

1шт.

120377

NUT,3/8" - 16, Gr 5

1шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

1шт.

3

274734R91

SCREEN ASSY, oil cooler fan chute

1шт.

4

318284R2

CHANNEL, oil cooler fan chute left

1шт.

5

318285R3

CHANNEL, oil cooler fan chute right

1шт.

6

318102R1

STRIP, Sta-Foam sealing

1шт.

7

318106R1

STRIP, Sta-Foam sealing

2шт.

8

318104R1

STRIP, Sta-Foam sealing

2шт.

9

150923C91

FRAME ASSY, oil cooler support

1шт.

17351R1

CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2

BOLT, 3/8 x 1 C-Z sq-nk crg

2шт.

18494R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

3/8 x 1 C-Z hex-hd mach

10шт.

18421R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G5, Full Thd

2шт.

120377

NUT,3/8" - 16, Gr 5

12шт.

271501

SOCKET

NUT, 7/16 C-Z hex

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

12шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

2шт.

575807R1

WASHER

13/32 x 1 x 11 ga

10шт.

10

150928C91

SUPPORT ASSY, oil cooler

1шт.

18684R1

BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2

3/8 x 1-1/4 C-Z sq-nk crg

4шт.

18695R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1 1/4", Gr 2

BOLT, 7/16 x 1-1/4 C-Z sq-nk crg

2шт.

120377

NUT,3/8" - 16, Gr 5

4шт.

NLS

NO LONGER SERVICED

NUT, 7/16 C-Z hex

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

2шт.

11

150930C1

STRAP, oil cooler tightener

1шт.

12

150931C1

STRAP, oil cooler support

1шт.

18795R1

BOLT,Hex, 7/16"-14 x 1 1/4", G2

7/16 x 1-1/4 C-Z hex-hd mach

2шт.

271501

SOCKET

NUT, 7/16 C-Z hex

2шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

2шт.

PO10534

WASHER

15/32 x 1-1/4 x 11 ga

2шт.

13

150932C1

ANGLE

oil cooler left

1шт.

18421R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G5, Full Thd

1шт.

NLS

NO LONGER SERVICED

NUT, 7/16 C-Z hex

1шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

1шт.

14

150933C1

ANGLE, oil cooler right tie

1шт.

18421R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G5, Full Thd

1шт.

271501

SOCKET

NUT, 7/16 C-Z hex

1шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

1шт.

15

150936C91

HUB ASSY, oil cooler fan

1шт.

16

150935C1

ANGLE, oil cooler tie rail

1шт.

17351R1

CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2

BOLT, 3/8 x 1 C-Z sq-nk crg

2шт.

120377

NUT,3/8" - 16, Gr 5

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

17

559203R1

SNAP RING,#118, 1.260", Int, Spiral

RING, oil cooler fan hub snap

1шт.

18

ST634

BEARING ASSY

BEARING, oil cooler fan hub ball

1шт.

19

150939C91

SHROUD ASSY, oil cooler fan

1шт.

181595

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5

SCREW, 5/16 x 3/4 C-Z hex-hd cap

8шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

8шт.

110579R91

NUT

5/16 speed grip

8шт.

20

387958R1

STRIP, Sta-Foam sealing

1шт.

21

150945C1

SUPPORT, oil cooler fan hub upper

2шт.

18764R1

HARDWARE,Hex, 5/16"-18 x 3/4", G2

BOLT, 5/16 x 3/4 C-Z hex-hd mach

5шт.

180075

BOLT,Hex, 5/16" - 18 x 5/8", Gr 5

SCREW, 5/16 x 5/8 C-Z hex-hd cap

2шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

SCREW, 5/16 x 3/4 C-Z hex-hd cap

2шт.

120376

NUT,5/16"-18, G5

5шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

9шт.

PO105311/2

WASHER, 11/32 x 1-1/2 x 11 ga

4шт.

22

150946C1

SUPPORT, oil cooler fan hub lower

1шт.

18764R1

HARDWARE,Hex, 5/16"-18 x 3/4", G2

BOLT, 5/16 x 3/4 C-Z hex-hd mach

3шт.

180075

BOLT,Hex, 5/16" - 18 x 5/8", Gr 5

SCREW, 5/16 x 5/8 C-Z hex-hd cap

1шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

SCREW, 5/16 x 3/4 C-Z hex-hd cap

1шт.

120376

NUT,5/16"-18, G5

3шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

5шт.

PO105311/2

WASHER, 11/32 x 1-1/2 x 11 ga

2шт.

23

150978C1

BOLT, oil cooler fan drive draw

1шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8-11 C-Z hex

3шт.

24

372724R1

PULLEY

oil cooler fan driven

1шт.

25

267450R91

BLADE ASSY, oil cooler fan 5 blade

1шт.

413-410

BOLT,Hex, 1/4" - 20 x 5/8", Gr 5

SCREW, 1/4 x 5/8 C-Z hex-hd cap

4шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

4шт.

26

159931C91

CHUTE ASSY, condenser air

1шт.

181595

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5

SCREW, 5/16 x 3/4 C-Z hex-hd cap

8шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

8шт.

110579R91

NUT

5/16 speed grip

8шт.

27

353443R91

LATCH ASSY.

LATCH ASSY, air chute screen

2шт.

113356

RIVET,Tr Hd, 3/16" x 3/8"

3/16 x 3/8 small ov-hd

4шт.

28

274733R1

DOOR, oil cooler fan chute

1шт.

29

151002C1

SIEVE, oil cooler fan drive shield

1шт.

30

628565R93

COMPRESSOR

ASSY

1шт.

31

936330R91

PULLEY AND CLUTCH, compressor driven

1шт.

181610

SCREW,Hex, 5/16" - 24 x 1 1/4", Gr 5

5/16 x 1-1/4 C-Z hex-hd cap

1шт.

22777V

WASHER, 11/32 x 7/8 x 3/16

1шт.

32

629733R91

LEAD BRUSH AND BRACKET ASSY

1шт.

33

936331R1

V-BELT,0.50" W

Compressor drive 0.50" W

1шт.

34

150911C1

PULLEY, compressor drive, (2) used belt drive machines, (1) used for hydrostatic machines

1шт.

180130

BOLT,Hex, 3/8" - 16 x 2", Gr 5

SCREW, 3/8 x 2 C-Z hex-hd cap

4шт.

113-257

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5

SCREW, 3/8 x 2-1/2 C-Z hex-hd cap, For diesel engine only

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

35

NOT USED

1шт.

36

155152C1

BRACE, compressor mounting bracket

1шт.

18494R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

3/8 x 1 C-Z hex-hd mach

1шт.

180126

BOLT,Hex, 3/8" - 16 x 1 1/2", Gr 5

SCREW, 3/8 x 1-1/2 C-Z hex-hd cap

1шт.

120377

NUT,3/8" - 16, Gr 5

1шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

1шт.

37

159942C1

SHIELD, fan drive belt

1шт.

18764R1

HARDWARE,Hex, 5/16"-18 x 3/4", G2

BOLT, 5/16 x 3/4 C-Z hex-hd mach

3шт.

16897R1

CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd

BOLT, 5/16 x 3/4 C-Z sq-nk crg

1шт.

120376

NUT,5/16"-18, G5

4шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

4шт.

Q397

WASHER

11/32 x 3/4 x 16 ga

2шт.

38

159941C1

SUPPORT, fan drive belt shield

1шт.

16897R1

CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd

BOLT, 5/16 x 3/4 C-Z sq-nk crg

1шт.

120376

NUT,5/16"-18, G5

1шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

39

632939R91

BASE ASSY, compressor mounting

1шт.

425-147

JAM NUT,Jam, 7/16"-14, G5

7/16-14 C-Z hex jam

1шт.

NLS

NO LONGER SERVICED

NUT, 7/16-14 C-Z hex

1шт.

40

632933R91

BRACKET ASSY, compressor mounting

1шт.

113-233

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

3/8-16 x 1-3/4 C-Z hex-hd

4шт.

16897R1

CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd

BOLT, 5/16 x 3/4 C-Z sq-nk crg

1шт.

18494R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

3/8 x 1 C-Z hex-hd mach

3шт.

120376

NUT,5/16"-18, G5

1шт.

120377

NUT,3/8" - 16, Gr 5

3шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

7шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

575807R1

WASHER

13/32 x 1 x 11 ga

4шт.

41

161076C91

BEARING ASSY,17 mm ID x 47 mm OD x 14 mm

compressor belt idler

2шт.

20299R1

BOLT, 5/8 x 3-3/4 C-Z hex-hd mach

1шт.

124589

BALL STUD,Hex, 5/8" - 11 x 2", Gr 5

5/8 C-Z hex

1шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

12258R1

WASHER

21/32 x 1-1/4 x 11 ga

7шт.

42

161092C91

PULLEY

RIM ASSY, compressor drive belt idler

2шт.

43

627389R1

SPACER,16.7mm ID x 22.23mm OD x 22.2mm L

compressor drive belt idler

1шт.

44

150934C1

CHANNEL, battery support

2шт.

17351R1

CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2

BOLT, 3/8 x 1 C-Z sq-nk crg

8шт.

120377

NUT,3/8" - 16, Gr 5

8шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

8шт.

159928C91

CONDENSER ASSY, Includes ref. nos. 45 thru 52

1шт.

937059R1

SCREW,Serr, M10 x 70mm, Cl 10.9

1/4 x 1/2 C-Z slt-truss-hd

4шт.

45

163655C91

CORE W/FITTINGS, condenser

1шт.

46

572832R91

CONTAINER

FILTER, receiver-dryer

1шт.

47

163659C1

U-BOLT, receiver filter

1шт.

178378

LOCK WASHER,Ext-Int Tooth, #10

NUT, no. 10-32 C-Z hex

2шт.

120614

NUT,Hex, #10 - 32

WASHER, no. 10 C-Z int-ext tooth lock

2шт.

48

163657C91

COUPLING ASSY, condenser

1шт.

49

163658C91

COUPLING ASSY, condenser

2шт.

50

159929C91

HOSE W/FITTINGS, 3/8 in., Serial Range: condenser-evaporator

1шт.

51

159930C91

A/C HOSE,0.41" ID x 48.00"

1/2" Discharge 0.41" ID x 48.00"

1шт.

52

399419R1

VALVE

ASSY

1шт.

53

159940C1

BAR

COVER, air chute tube opening

2шт.

145189

SCREW, no. 10 x 3/8 slt-pan-hd tap

2шт.

54

155482C1

CLIP

thermostat

1шт.

55

155491C91

THERMOSTAT

ASSY

1шт.

56

150960C1

V-BELT,113.79" L

Oil Cooler Fan Drive 113.79" L

1шт.

57

142350

GROMMET,7/8" ID x 1 5/8" x .125", Diag Cut

rubber hose

2шт.

58

NOT USED

1шт.
