Артикул
Название
Примечание
Количество
1
631143R92
PUMP
ASSY, hydraulic lift, For components see list of parts under details of hydraulic pump
1шт.
2
154680C92
PUMP
ASSY, hydraulic lift, For components see list of parts under details of hydraulic leveling pump
1шт.
3
9410978
ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, O-Ring
7/8-14 90 deg
7шт.
4
9410981
ELBOW,90 Degree, 1 5/16"-12, 37 Degree x 1 5/16"-12, O-Ring
1-15/16-12 90 deg
3шт.
5
296247R1
O-RING,16-1, 90 Duro, 1.171" ID x .116" Thk
for 1 in. OD tube
8шт.
6
364885R1
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
3/4 x 15/16 x 3/32
16шт.
7
167945C1
TEE, reservoir return
1шт.
8
9410979
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, O-Ring
1-1/16 90 deg
3шт.
9
368269R1
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
for 1 in. OD tube
11шт.
10
172003C91
RESERVOIR ASSY, hydraulic oil, For components see list of parts under hydraulic oil reservoir
1шт.
11
9410205
HYD CONNECTOR,1 1/16"-12, 37 Degree x 1 1/16"-12, O-Ring
CONNECTOR, 1-1/16-12 37 deg
2шт.
12
573200R91
FILTER
ASSY, hydraulic oil, For components see list of parts under details of hydraulic oil filter
1шт.
13
573206R1
HYD CONNECTOR,7/8"-14, 37 Degree x 1 1/16"-12, O-Ring
CONNECTOR, 7/8-14 37 deg
2шт.
14
633460R91
ELBOW,90 Degree, 7/8"-14, 37 Degree x 1 1/16"-12, O-Ring
hydraulic oil filter
2шт.
15
378578R95
HYDRAULIC STEERING
PUMP ASSY, steering hand, For components see list of parts under details of hand steering pump
1шт.
16
9410203
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
CONNECTOR, 3/4-16
5шт.
18
406887R94
PUMP
ASSY, ground drive, For components see list of parts under details of ground drive pump assy
1шт.
271563
SUPPORT,Hex, 5/8" - 11 x 2 1/4", Gr 5
SCREW, 5/8 x 2-1/4 hex-hd cap
4шт.
120639
NUT, 5/8 hex.
4шт.
103325
LOCK WASHER,5/8"
WASHER, LOCK, 5/8"
4шт.
614774R1
WASHER, 21/32 x 1-11/16 x 3/16
4шт.
19
163915C1
FITTING
CONNECTOR, 1-15/16-12 37 deg
3шт.
20
574479R1
HYD CONNECTOR,1 1/16"-12, 37 Degree x 7/8"-14, O-Ring
CONNECTOR, 7/8-14
1шт.
21
156571C91
FILTER CARTRIDGE
FILTER ASSY, oil, For components see list of parts under details of oil filter assy
1шт.
22
167949C1
TUBE ASSY, foot-n-inch valve upper
1шт.
23
165626C92
TUBE
ASSY, foot-n-inch valve lower
1шт.
24
164407C92
TUBE
ASSY, foot-n-inch valve lower rear
1шт.
25
403346R92
MOTOR
ASSY, ground drive, For components see list of parts under details of ground drive motor assy
1шт.
413-828
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
4шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
4шт.
283856C1
WASHER
17/32 x 1 x 7 ga
4шт.
26
595408R1
90 ELBOW
1-15/16 90 deg
1шт.
27
150947C91
COOLER ASSY, oil
1шт.
18764R1
HARDWARE,Hex, 5/16"-18 x 3/4", G2
BOLT, 5/16 x 3/4 C-Z hex-hd mach
8шт.
120376
NUT,5/16"-18, G5
8шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
8шт.
28
9410204
HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring
CONNECTOR, 7/8-14
1шт.
29
570799R91
CYLINDER ASSY, platform lift
2шт.
30
587582R91
HOSE ASSY.
HOSE ASSY, platform lift cylinder
2шт.
31
9410977
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, O-Ring
3/4-16 9 deg
9шт.
32
633309R91
CYLINDER ASSY, steering, For components see list of parts under detail of steering cylinder
1шт.
33
9410976
ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
5шт.
34
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
6-1, 90 Duro, .468" ID x .078" Thk, for 3/8 OD tube
8шт.
35
583894R92
CYLINDER ASSY, side leveling, For components see list of parts under details of side leveling cylinder
1шт.
36
633312R91
CYLINDER ASSY, rear leveling, For components see list of parts listed under details of rear leveling cylinder
2шт.
37
VALVE ASSY, propulsion drive and platform lift, For components see list of parts under details of propulsion drive and platform lift valve
1шт.
38
587577R1
CONNECTION,1 1/16"-12, 37 Degree x 3/4"-16, O-Ring
CONNECTOR, 3/4-16
1шт.
39
164408C91
TUBE ASSY, foot-n-inch valve return
1шт.
40
527492R91
LOCK VALVE
VALVE ASSY, steering, For components see list of parts under details of steering valve
1шт.
41
9410202
HYD CONNECTOR,9/16"-18, 37 Degree x 9/16"-18, O-Ring
CONNECTOR, 9/16-18
2шт.
42
9402979
TEE,7/16"-20, 37 Degree
7/16-20 hyd tube
1шт.
43
403347R91
LOCK VALVE
VALVE ASSY, foot-n-inch pilot relief, For components see foot-n-inch control pedal and valve
1шт.
44
573902C93
VALVE ASSY, rear and side leveling, For components see list of parts listed under detail of rear and side leveling
1шт.
45
164419C1
CONNECTOR, 1/2-20 hyd tube
1шт.
46
936450R1
ELBOW
7/8-14 90 deg
6шт.
47
150886C91
FLOW DIVIDER ASSY, For components see list of parts listed under details of flow divider
1шт.
49
150861C1
SUPPORT, flow divider
1шт.
702222
SUPPORT
SCREW, 1/4 x 2-1/4 hex-hd cap
2шт.
179818
BOLT,Hex, 5/16" - 18 x 1", Gr 5
2шт.
109084
NUT,1/4"-20, G5
2шт.
9635082
NUT,5/16" - 18, Gr 5
5/16 hex.
2шт.
103319
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
2шт.
50
150885C91
HOSE,0.38" ID x 25.00", SAE 100R1
Flow Divider to Return Tee 0.38" ID x 25.00", SAE 100R1
1шт.
51
347186R91
HOSE
ASSY, flow divider to leveling valve
1шт.
52
628685R11
TUBE ASSY, steering flow divider to valve rear
1шт.
53
164409C91
TUBE ASSY, steering return
1шт.
54
587575R91
HYDRAULIC HOSE,0.31" ID x 24.00", SAE 100R1
HOSE ASSY, power steering tube to steering cylinder
2шт.
55
588532R11
TUBE ASSY, steering flow divider to valve center 0.375" OD, 45.81, 7.22" Length
1шт.
56
939256R11
PIPE ASSY, steering flow divider to valve front
1шт.
57
588534R11
PIPE ASSY, steering valve to cylinder upper front
1шт.
58
588535R11
TUBE ASSY, steering rear bail lower
1шт.
59
939252R11
PIPE ASSY, steering hand pump to valve pressure, RH
1шт.
60
633206R11
TUBE ASSY, steering front bail upper
1шт.
61
633207R11
TUBE ASSY, steering rear bail upper
1шт.
62
633208R11
TUBE ASSY, steering valve to cylinder lower front
1шт.
63
633209R11
TUBE ASSY, steering front bail lower
1шт.
64
939254R11
PIPE ASSY, steering hand pump to valve pressure, LH
1шт.
65
632454R91
HYDRAULIC HOSE,0.31" ID x 30.00", SAE 100R1 Class B
HOSE ASSY, steering lower
1шт.
66
632455R91
HOSE
ASSY, cylinder to lower tubing
2шт.
67
935765R1
CLIP, front pressure steering tube
3шт.
68
589980R2
CLIP
steering cylinder tube and hose
6шт.
17425R1
BOLT,Hex, 5/16" - 18 x 1", Gr 2
5/16 x 1 hex-hd
1шт.
9635082
NUT,5/16" - 18, Gr 5
5/16 hex.
1шт.
69
56522R1
CLIP, valve to cylinder front tube
3шт.
70
561529R1
CLIP, steering valve to cylinder bail tube
5шт.
17410R1
BOLT,Hex, 1/4" - 20 x 3/4", Gr 2
1/4 x 3/4 hex-hd
4шт.
17424R1
BOLT,Hex, 1/4" - 20 x 1"
1/4 x 1 hex-hd
1шт.
109084
NUT,1/4"-20, G5
5шт.
103319
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
5шт.
71
427313R91
HOSE CLAMP,#116, 6.88/7.75 Type F Worm
CLAMP ASSY, rear bail tube
1шт.
71
274090R91
HOSE CLAMP,3.75/4.63 Type F Worm
CLAMP ASSY, side leveling cylinder
1шт.
71
274089R91
CLAMP
ASSY, platform lift tube
1шт.
72
654600R11
TUBE ASSY, axle to cyl to hose steering
2шт.
73
151798C91
PIPE ASSY, steering valve to cylinder front extension
1шт.
74
151799R91
PIPE ASSY, steering valve to cylinder front extension
1шт.
75
563941R92
HOSE ASSY, leveling cylinder
2шт.
76
587582R91
HOSE ASSY.
HOSE ASSY, rear leveling cylinder
4шт.
77
567895R2
CLIP, hydraulic tube
10шт.
78
150908C92
PIPE ASSY, filter to rear leveling valve front
1шт.
79
573099R92
CLIP, hydraulic tube leveling return
5шт.
80
309135R91
HOSE ASSY, Serial Range: pump-filter
2шт.
81
587501R2
CLAMP
CLIP, hydraulic tube
15шт.
18764R1
HARDWARE,Hex, 5/16"-18 x 3/4", G2
BOLT, 5/16 x 3/4 C-Z hex-hd
7шт.
12872R1
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
5/16 x 3/4 C-Z sq-nk crg
2шт.
120376
NUT,5/16"-18, G5
7шт.
48
369384R1
O-RING,0.072" Thk x 0.414" ID, -905, Cl 6, 90 Duro
5-1, 90 Duro, .414" ID x .072" Thk, For 5/16 OD tube
1шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
9шт.
82
588322R1
CLIP
2шт.
17445R1
BOLT,Hex, 5/16" - 18 x 1 1/4"
5/16 x 1-1/4 hex-hd
1шт.
9635082
NUT,5/16" - 18, Gr 5
5/16 hex.
1шт.
83
588529R11
TUBE ASSY, filter to rear leveling valve 0.625" OD, 34.55" Length
1шт.
84
588745R11
TUBE ASSY, rear cylinder cross over 1" OD, 41, 10.75" Length
1шт.
85
628678R11
TUBE ASSY, filter to side leveling valve rear 0.625" OD, 36.56, 11.88" Length
1шт.
86
150887C91
TUBE ASSY, filter to side leveling valve front
1шт.
87
628722R11
TUBE ASSY, side leveling pressure ext
1шт.
88
628719R11
TUBE ASSY, leveling valve bleed center
1шт.
89
588746R11
TUBE ASSY, cylinder hose to cross over tube rear
1шт.
90
150910C91
TUBE ASSY, rear leveling pressure extension front
1шт.
91
150909C91
TUBE ASSY, rear leveling pressure return front
1шт.
92
588536R11
TUBE ASSY, leveling return cross over
1шт.
93
628724R11
TUBE ASSY, side leveling pressure return
1шт.
94
150864C91
TUBE ASSY, leveling return front
1шт.
95
628691R11
TUBE ASSY, leveling return center 0.75" OD, 46.68, 17.68" Length
1шт.
96
628682R11
TUBE ASSY, rear leveling valve to cylinder bottom
1шт.
97
628683R11
TUBE ASSY, rear leveling valve to cylinder top
1шт.
98
628675R11
TUBE ASSY, side leveling cylinder upper 0.5" OD, 19.5" Length
2шт.
99
628676R11
TUBE ASSY, rear leveling center lower 0.5" OD, 81.5, 25.38" Length
1шт.
100
628677R11
TUBE ASSY, cylinder hose to cross over tube front
1шт.
101
628681R11
TUBE ASSY, rear leveling center upper 0.5" OD, 82.68, 22.44" Length
1шт.
102
633301R91
HOSE ASSY, leveling return
1шт.
103
154683C91
HOSE ASSY, leveling suction
1шт.
104
628684R11
TUBE ASSY, front bleed
1шт.
105
628692R11
TUBE ASSY, leveling return rear 0.75" OD, 31.12, 5.06" Length
1шт.
106
167947C1
TUBE ASSY, rear bleed
1шт.
107
628741R11
TUBE ASSY, side to rear leveling bleed 0.375" OD, 14.81, 1.84" Length
1шт.
108
167748C1
ANGLE, rear leveling tube
2шт.
17411R1
BOLT,Hex, 5/16"-18 X 3/4", G2
5/16 x 3/4 hex-hd
4шт.
9635082
NUT,5/16" - 18, Gr 5
5/16 hex.
4шт.
109
633127R1
BRACKET, leveling system pressure tube
1шт.
110
150860C1
BRACKET, leveling tube front
1шт.
15140R1
BOLT
1/4 x 3 sq-nk crg
3шт.
109084
NUT,1/4"-20, G5
3шт.
103319
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
3шт.
111
558412R91
HOSE
ASSY, hydraulic oil filter
2шт.
112
567852R1
BRACKET, rear level rear tube clip
1шт.
17411R1
BOLT,Hex, 5/16"-18 X 3/4", G2
5/16 x 3/4 hex-hd
2шт.
9635082
NUT,5/16" - 18, Gr 5
5/16 hex.
2шт.
113
167944C1
ANGLE, tube clip
1шт.
179818
BOLT,Hex, 5/16" - 18 x 1", Gr 5
1шт.
9635082
NUT,5/16" - 18, Gr 5
5/16 hex.
1шт.
114
564563R1
BRACKET, rear level tube clip, on cylinder beater angle right side
1шт.
17426R1
BOLT,Hex, 3/8" - 16 x 1", Gr 2
3/8 x 1 hex-hd
1шт.
102635
NUT,3/8"-16, G5
1шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
1шт.
115
150874C91
CLAMP ASSY, hydraulic tube holder
2шт.
116
631163R91
HOSE ASSY.
HOSE ASSY, valve pressure
1шт.
117
154883C91
TUBE ASSY, platform lift cylinder upper
1шт.
118
154884C91
TUBE ASSY, platform lift cylinder lower
1шт.
119
588538R91
TUBE ASSY, front return, Not for hydraulic reel drive
1шт.
119
935673R91
TUBE ASSY, front return, For hydraulic reel drive
1шт.
120
167935C1
TUBE ASSY, rear return
1шт.
121
154821C91
TUBE ASSY, platform lift suction
1шт.
122
154683C91
HOSE ASSY, pump suction
1шт.
123
573900R91
HOSE ASSY, pump pressure
1шт.
124
627441R11
TUBE ASSY, lower pressure 0.625" OD, 72, 5.43" Length
1шт.
125
588531R11
TUBE ASSY, rear pressure
1шт.
126
633301R91
HOSE ASSY, platform lift return
1шт.
127
150773C91
PIPE ASSY, motor to pump upper bleed
1шт.
128
167933C1
PIPE ASSY, motor to pump lower bleed
1шт.
129
164089C91
TUBE
ASSY, forward pressure lower
1шт.
180124
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
3/8 x 1-1/4 C-Z hex-hd
4шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
4шт.
130
167936C1
TUBE ASSY, forward pressure upper
1шт.
131
164091C91
TUBE
rearward pressure upper
1шт.
132
167937C1
TUBE ASSY, rearward pressure upper
1шт.
180124
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
3/8 x 1-1/4 C-Z hex-hd
4шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
4шт.
133
343906R1
O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro
1-5/16 x 1-9/16 x 1/8
2шт.
134
164722C1
SLEEVE, hyd ground drive tube rubber
4шт.
135
167934C1
TUBE ASSY, ground drive pump to oil cooler
1шт.
136
167932C1
TUBE ASSY, reservoir to oil cooler
1шт.
137
153677C91
HOSE ASSY, filter to ground drive
1шт.
138
155225C91
HOSE ASSY.
HOSE ASSY, cooler
2шт.
139
150785C91
HOSE ASSY, Serial Range: reservoir-filter
2шт.
140
150778C1
CLAMP, hydraulic pipe upper
1шт.
140
157678C1
CLAMP
hydraulic pipe lower
1шт.
141
150780C1
STRAP
hydraulic pipe cushion upper
1шт.
141
157783C1
STRAP, hydraulic pipe cushion lower
1шт.
271501
SOCKET
NUT, 7/16 C-Z hex.
4шт.
120383
LOCK WASHER,Helical Spring, 7/16"
WASHER, LOCK, 7/16"
4шт.
142
150779C1
TUBE
STRAP, hydraulic pipe cushion
2шт.
143
574018R1
HYD CONNECTOR,1 5/16"-12, 37 Degree x 1 1/16"-12, O-Ring
CONNECTOR, 1-1/16-12 hyd tube
1шт.
Выбрано товаров: 199
