Запчасти Case IH 1482 (21-09) - THRESHING ROTOR AND CONCAVES, CONE (14) - THRESHING

1

454502R1

LATCH

separator front door

2шт.

648002

KNIFE

1/8" x 3/4"

1шт.

120394

WASHER,3/8", SAE

WASHER, .406 x .812 x .051

1шт.

2

M296

SPRING

front door latch

2шт.

3

193608C2

DOOR

separator front

1шт.

4

160638C1

HANDLE

rotor front door

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

477-73108

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"

5/16 x 1/2 slt-truss-hd

1шт.

5

182974C93

DOOR

rotor front, Includes: Ref. 10

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

3/8 flange lock

1шт.

135270

SERRATED SCREW,5/16" - 18 x 3/4"

5/16 x 3/4 znp slt-truss-hd

1шт.

477-73812

SERRATED SCREW,Truss HD, 3/8" - 16 x 3/4"

3/8 x 3/4 znp slt-truss-hd

1шт.

6

NOT USED IN THIS APPLICATION

1шт.

7

1317778C2

CONE

ASSY, transition, Replaces 186775C6

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

3/8 flange lock

1шт.

487374R1

BEARING LOCK NUT,Flg, USR, 1/2"-13

1/2 flange lock

1шт.

135270

SERRATED SCREW,5/16" - 18 x 3/4"

5/16 x 3/4 znp slt-truss-hd

1шт.

186917C1

SCREW

SCREW, 3/8 x 1 slt-truss-hd w/ scotch grip

1шт.

204060C1

BOLT,Hex Serr Flg, 1/2" - 13 x 1 1/4"

SCREW, 1/2 x 1-1/4 slt-truss-hd

1шт.

8

195202C1

SEAL

feeder

2шт.

9

195409C1

PLATE

seal backup

2шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

10

179749C2

PRODUCT GRAPHIC

danger

1шт.

11

1302141C2

SUPPORT

LH pocket, For use with cone 186775C6

1шт.

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

3/8 flange lock

1шт.

154273C1

BOLT,Hex Serr, 3/8" - 16 x 1", Spcl

SCREW, 3/8-16 x 1 lock

1шт.

12

120253C1

CONDUIT

LH pocket support, 8.25 in. - 209.66 mm

1шт.
