Запчасти Case IH 1670 (6-50) - REAR WHEEL DRIVE, DRIVE MOTOR SYSTEM (03) - POWER TRAIN

1

1343615C1

MOTOR

ASSEMBLY - hydrostatic, parts list figure 6-56

2шт.

2

1331339C1

ELBOW

TUBE - elbow, 37 degree

4шт.

3

238-6219

O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro

4шт.

4

S97224

CLAMP

- split flange, 1 inch

8шт.

5

413-728

BOLT,Hex, 7/16" - 14 x 1-3/4", Gr 5

16шт.

6

492-11044

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

16шт.

7

1304872C1

HYD TUBE,0.5" OD, 3.56, 1.2" Length

TUBE - motor drain

2шт.

8

218-5070

HYD CONNECTOR,3/4" - 16 Male JIC x 1-1/16" - 12 Male ORB

ADAPTER - straight, 3/4-16 flare x 1-1/16-12 inch O-ring boss, Includes: Ref. 9

2шт.

9

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

12-1, 90 Duro, .924 ID x .116" Thk

2шт.

12

1331356C1

TUBE ASSY.

TUBE - drive motor

1шт.

13

1331357C1

HYD TUBE

TUBE - drive motor

1шт.

14

1331358C1

HYD TUBE

TUBE - drive motor

1шт.

15

165601C1

CLAMP

- reservoir drain tube

2шт.

16

163493C1

STRIP,19.05mm ID x 25.4mm OD x 45.7mm L

SLEEVE - rubber, 3/4 ID x 1-13/64 inch long

4шт.

17

413-628

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

- hex, 3/8 NC x 1-3/4 inch

2шт.

18

492-11038

LOCK WASHER,3/8"

2шт.

19

1331355C1

HYD TUBE

TUBE - drive motor

1шт.

21

1304283C3

HOSE ASSY.,19.05mm ID x 1016mm L, SAE 100R10

HOSE ASSY, , CLASS 12, Drive Motor Pressure 0.75" ID x 40.00", SAE 100R10

4шт.

22

D52256

HOSE

- header lift cylinder, 45 inch, if used (Replaces hose 1310709C1)

2шт.

22

813610C1

HOSE

- header lift cylinder, 50 inch, if used

2шт.

23

1304881C1

HYD TUBE,1" OD, 1447.8, 184.1 mm Length

TUBE - drive forward pressure

1шт.

24

1304873C1

HYD TUBE,0.5" OD, 48.3, 3.34" Length

TUBE - drain

1шт.

25

1304882C1

HYD TUBE,1" OD, 1518.9, 174 mm Length

TUBE - drive reverse pressure

1шт.

26

1304493C1

SUPPORT

BRACKET - tube support

2шт.

27

276-14912

SELF-TAP SCREW,Hex Hd, 3/8" x 3/4"

SCREW - self-tapping, hex head, 3/8 NC x 3/4 inch

4шт.

28

413-520

BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5

- hex, 5/16 NC x 1-1/4 inch

2шт.

29

413-536

BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5

- hex, 5/16 NC x 2-1/4 inch

4шт.

30

1304633C1

SUPPORT

CLAMP - tube retaining

2шт.

31

1304634C1

SUPPORT

CLAMP - tube retaining

2шт.

32

27311R1

NUT

- hex, 5/16 inch NC

2шт.

33

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

6шт.

34

163491C1

RUBBER INSULATOR

INSULATOR - rubber, 1/2 ID x 1-13/64 inch long

4шт.

35

187935C1

STRIP

SLEEVE - pressure tube clamp

4шт.
