Запчасти Case IH 1670 (6-48) - MAIN DRIVE SHAFT (03) - POWER TRAIN
26
5
32
21
3
4
7
14
6
1
4
5
28
23
21
7
15
30
2
3
17
16
21
24
2
35
21
1
25
31
3
22
2
13
9
6
3
12
8
4
9
22
2
8
34
4
33
27
19
18
29
№
Артикул
Название
Примечание
Количество
184142C91
DRIVE SHAFT
SHAFT ASSEMBLY - main drive, Includes: Ref. 1 - 8
2шт.
1
NSS
NOT SOLD SEPARAT
SHAFT - drive (Order 184142C91)
1шт.
2
184115C1
YOKE
- drive shaft, flanged
1шт.
3
184126C1
YOKE
- drive shaft, splined
1шт.
5
184143C1
U-JOINT SPIDER
CROSS ASSEMBLY - drive shaft, Includes: Ref. 6 - 8
2шт.
6
NSS
NOT SOLD SEPARAT
COVER - drive shaft cross
2шт.
7
NSS
NOT SOLD SEPARAT
RETAINER - cross cover
2шт.
8
NSS
NOT SOLD SEPARAT
BOLT - cover retaining
4шт.
12
184154C1
BOLT
- retaining
2шт.
13
184141C1
WASHER
- bolt retaining
2шт.
Выбрано товаров: 10
