Запчасти Case IH 1670 (3-12) - FUEL TANK AND SUPPORTS (02) - FUEL SYSTEM

1

193550C95

FUEL TANK

TANK ASSEMBLY - fuel (Replaces tank assembly 193550C94), Includes: Ref. 2

1шт.

2

104781C1

CAP

- fuel tank, non-vented, if used

1шт.

2

23995DC

FILLER CAP

CAP - vented, fuel tank filler, extra dirty condition, if used

1шт.

3

NSS

NOT SOLD SEPARAT

STRIP - fuel tank support, lining, 72 inch long (Order 990539R1, Serial Range: cut-length)

2шт.

990539R1

STRIP

- lining, 1-1/4 (32) wide x 600 inch (15240 mm) long, cut from 50 foot bulk roll

1шт.

4

192381C3

SUPPORT

ANGLE - lower support, fuel tank

2шт.

5

1302029C1

SUPPORT

ANGLE - front support, fuel tank

2шт.

6

198024C1

FUEL GAUGE

SENSOR - sending unit, fuel level

1шт.

7

168515C1

GASKET,3.05mm Thk

- fuel tank sending unit

1шт.

8

1310675C1

CAPTIVE WASHER SCREW,Sl Truss Hd, #10 - 24 x 0.75"

SCREW, LOCK, , Sending unit mounting Sltd Truss Hd, #10-24 x 3/4", w/nylon LW

5шт.

9

1302031C1

STRAP

SUPPORT - strap, fuel tank retainer

2шт.

10

1302030C1

ANGLE

ANGLE - front, fuel tank

2шт.

11

409-7512

BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl

- hex serrated flange, 5/16 NC x 3/4 inch

2шт.

12

495-81112

WASHER,.344" x 3/4" x .120"

- flat, 11/32 x 3/4 x 7/64 inch

4шт.

13

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

4шт.

14

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

4шт.

15

409-7516

BOLT,Hex Flg, 5/16" - 18 x 1", Spcl

2шт.

16

135270

SERRATED SCREW,5/16" - 18 x 3/4"

- slotted truss head, 5/16 NC x 3/4 inch, if used

19шт.

16

433-540

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 2 1/2", Gr 5

BOLT - carriage, 5/16 NC x 2-1/2 inch, if used

1шт.

16

409-7516

BOLT,Hex Flg, 5/16" - 18 x 1", Spcl

If used Hex Flg, 5/16"-18 x 1", Serr

19шт.

17

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

28шт.
