Запчасти Case IH 1670 (7-14) - MAIN FRONT DISC BRAKES (5.1) - BRAKES

1

1304295C92

BRAKE

CALIPER ASSEMBLY - front disc brake, Includes seal and kit

4шт.

1304286C2

SEAL

- caliper brake, not shown

2шт.

1304298C3

BRAKE

KIT - caliper brake

1шт.

2

1304939C1

TUBE

VALVE - bleeder

4шт.

3

326-14104

BOLT,Hex, 7/8" - 9 x 6-1/2", Gr 8

8шт.

4

1304666C1

WASHER

- brake caliper

8шт.

5

392-21088

LOCK WASHER,7/8"

7/8"

8шт.

6

329-1014

NUT,7/8"-9, G8

8шт.

7

218-5102

ELBOW,90 Degree Elbow, 3/8" - 24 Male JIC x 3/8" - 24 Male ORB

- 90 degree adjustable (Replaces elbow 9410973)

8шт.

8

1304938C1

OIL SEAL

O-RING - sealing, 3/16 inch O.D.

8шт.

9

1317158C1

HYD TUBE,0.1875" OD, 95, 38 mm Length

TUBE - front brake, upper

4шт.

10

218-5152

PLUG,Hex Hd, 3/8"-24 ORB

(Replaces plug 9410355), Includes Ref. 10A Hex Hd, 3/8"-24 ORB

16шт.

10a

218-5002

O-RING,0.064" Thk x 0.301" ID, -903, Cl 6, 90 Duro

3-1, .301" ID x .064" Thk

16шт.

15

201-100

HYD CONNECTOR,9/16" - 18 Male ORFS x 7/16" - 20 Male ORB

ADAPTER - straight 9/16-18 face seal x 7/16-20 inch O-ring boss

2шт.

15

218-5053

HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB

ADAPTER - straight, 7/16-20 inch flare x O-ring boss, Incl. Ref. 15A

2шт.

15a

895644C1

O-RING,0.351" ID x 0.495" OD x 0.072"

O-RING - sealing

2шт.

16

218-5103

90 ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 7/16" - 20 Male ORB

- 90 degree, 7/16-20 inch flare x adj. O-ring boss, Includes: Ref. 16A

2шт.

16a

895644C1

O-RING,0.351" ID x 0.495" OD x 0.072"

O-RING - sealing

2шт.

18

1304807C1

TUBE ASSY.,0.25" OD, 4.7, 2.8" Length

TUBE - brake, lower front

2шт.

19

218-841

TEE,37 Degree, 7/16"-20 x 7/16"-20, Fem Sw Br

- 7/16-20 swivel straight thread branch x flare x flare (Replaces tee 9410304)

2шт.

20

1304810C1

HYD TUBE

TUBE - brake pivot arm

2шт.

21

222-1053

HYD CONNECTOR,1/4" Inv Fl

COUPLING - 7/16-24 inch inverted flare (Replaces union 442336)

6шт.

22

1304296C2

HOSE

- pivot, front brake

2шт.

25

1304919C1

TUBE ASSY.

TUBE - front brake, right-hand

1шт.

26

1331307C1

TUBE ASSY.

TUBE - brake, lower right-hand

1шт.

27

1321511C2

HYD TUBE

TUBE - brake, center

2шт.

28

1304811C1

TUBE ASSY.

TUBE - front brake, left-hand

1шт.

29

1331306C1

TUBE ASSY.

TUBE - brake, lower left-hand

1шт.

32

1321476C2

HYD TUBE

TUBE - brake, upper right-hand

1шт.

33

1321475C2

HYD TUBE

TUBE - brake, upper left-hand

1шт.

34

201-100

HYD CONNECTOR,9/16" - 18 Male ORFS x 7/16" - 20 Male ORB

ADAPTER - straight, 9/16-18 face seal x 7/16-20 inch O-ring boss, Includes: Ref. 35

2шт.

35

237-3004

O-RING,0.351" ID x 0.072" Width

4-1, Cl 3, .351" ID x .072" Thk

2шт.

36

218-5228

ELBOW,90 Degree, 7/16"-20, 37 Degree x 7/16"-20, 37 Degree Fem Sw

- 90 degree, 7/16-20 inch flare x swivel

2шт.

37

1281884C91

MASTER CYLINDER,37mm Stroke

ASSEMBLY - master brake, parts list figure 7-16

2шт.

38

1304289C1

SHIM

- caliper, 0.06 inch

1шт.

38

1304288C1

SHIM

- caliper, 0.12 inch

1шт.

39

515-2863

CLAMP,1/4", 3/8" Bolt

- P-type, 1/4 inch closed

8шт.

40

281-14812

SELF-TAP SCREW,Hex Washer, 5/16" - 18 x 3/4"

SCREW - self-tapping, hex washer head, 5/16 NC x 3/4 inch

8шт.

41

163492C1

RUBBER INSULATOR

INSULATOR - rubber, 5/8 ID x 1-13/64 inch long

16шт.

42

196868C1

BAR

SUPPORT - cooler, brake tube

1шт.
