Запчасти Case IH 1670 (1-28) - PICTORIAL INDEX, LEVELING SYSTEM (00) - PICTORIAL INDEX

1

Leveling Return Hose, Page 8-81

1шт.

2

Leveling Return Tube, Page 8-81

1шт.

3

Leveling Return Tube, Page 8-81

1шт.

4

Leveling Return Hose, Page 8-81

1шт.

5

Leveling Return Hose, Page 8-81

1шт.

6

Upper Leveling Return Tube, Page 8-81

1шт.

7

Hydraulic Leveling Pressure Tube, Page 8-83

1шт.

8

Leveling Pump Suction Hose, Page 8-81

1шт.

9

Leveling Slow Speed Hose, Page 8-81

1шт.

10

Leveling High Speed Hose, Page 8-81

1шт.

11

Bypass to Check Valve Hose, Page 8-81

1шт.

12

Upper Leveling Pressure Tube, Page 8-81

1шт.

13

Adapter Tube, Page 8-81

1шт.

14

Leveling Pressure Tube, Page 8-81

1шт.

15

Hydraulic Leveling Pressure Tube, Page 8-83

1шт.

16

Hydraulic Leveling Pressure Tube, Page 8-83

1шт.

17

Leveling Cylinder Hose, Page 8-83

1шт.

18

Lower Pressure Crossover Tube, Page 8-83

1шт.

19

Leveling Cylinder Hose, Page 8-83

1шт.

20

Hydraulic Leveling Pressure Tube, Page 8-83

1шт.

21

Leveling Cylinder Hose, Page 8-83

1шт.

22

Upper Pressure Crossover Tube, Page 8-83

1шт.

23

Leveling Cylinder Hose, Page 8-83

1шт.

24

Leveling Bypass Return Tube, Page 8-83

1шт.
