Запчасти Case IH 1670 (4-56) - BATTERY AND BATTERY CABLES (06) - ELECTRICAL

1

BMF31GS

DRY BATTERY

BATTERY - dry charged, 12 volt

2шт.

2

245739C1

BUSHING,3/8"-16, 19mm OD x 31.75mm W

- jump start

1шт.

3

476074C1

NUT

- hex flange, 3/8 inch NC

4шт.

6

1979667C1

CABLE

ASSEMBLY - battery positive, Includes: Ref. 7 and 8

1шт.

7

NSS

NOT SOLD SEPARAT

BOOT - battery cable

2шт.

8

NSS

NOT SOLD SEPARAT

BOOT - battery cable

1шт.

12

245226C2

CABLE PULLING GRIP

CABLE ASSEMBLY- battery, ground, Includes: Ref. 13 and 14

1шт.

13

NSS

NOT SOLD SEPARAT

BOOT - battery cable

2шт.

14

NSS

NOT SOLD SEPARAT

BOOT - battery cable

1шт.

19

158477C91

CABLE

- cab and valve bank ground

2шт.

20

413-632

BOLT,Hex, 3/8" - 16 x 2", Gr 5

1шт.

21

492-11038

LOCK WASHER,3/8"

1шт.

22

425-106

NUT,3/8"-16, Cl 5

1шт.

25

702093C1

CABLE TIE

STRAP - tie, self-locking, black

1шт.

26

515-23254

CLAMP,1", Insul, 3/8" Bolt

P-type 1", Insul, 3/8" Bolt

10шт.
