Запчасти Case IH 1670 (4-54) - BATTERY TRAY (06) - ELECTRICAL

1

194267C6

TRAY

- battery (Replaces battery tray 194267C5)

1шт.

2

135270

SERRATED SCREW,5/16" - 18 x 3/4"

- slotted truss head, 5/16 NC x 3/4 inch, if used

4шт.

2

409-7516

BOLT,Hex Flg, 5/16" - 18 x 1", Spcl

If used Hex Flg, 5/16"-18 x 1", Serr

4шт.

3

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

4шт.

4

194266C1

SUPPORT

- battery tray

1шт.

7

188116C1

CLAMP

- battery hold down

1шт.

8

411-5152

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 9 1/2", Gr 2

BOLT - carriage, 5/16 NC x 9-1/2 inch, grade 2

2шт.

9

495-11034

WASHER,5/16", SAE

5/16" SAE (flat, 11/32 x 11/16 x 1/16")

2шт.

10

129-419

WING NUT,5/16"-18

NUT - wing, 5/16 inch NC

2шт.
