Запчасти Case IH 1670 (4-36) - LAMP ASSEMBLIES, CAB SPOTLAMP, GRAIN TANK LAMP, FEEDER LAMP, UNLOADER LAMP (06) - ELECTRICAL

1323590C91

LAMP BASE

KIT - spotlamp, Includes: Ref. 1 - 8

1шт.

1

1329859C1

BRACKET

- spotlamp

2шт.

2

1330144C1

GROMMET

- spotlamp

1шт.

3

1330145C1

BUSHING

- spotlamp

1шт.

4

91938C1

INTERIOR LIGHT

SPOTLAMP - cab

1шт.

5

92015C1

BRACKET

- spotlamp

1шт.

6

A149798

FUSE

- tan, 5 ampere

1шт.

6

A149799

FUSE

- brown, 7-1/2 ampere

1шт.

7

265-1358

SELF-TAP SCREW,Cross Oval Hd, #10 x 1/2"

SCREW - self-tapping, oval Phillips, No. 10-16 x 1/2 inch

2шт.

8

264-2056

SELF-TAP SCREW,Slotted Pan Hd, #10 x 3/8"

SCREW - self-tapping, pan head slotted, No. 10 NC x 3/8 inch

2шт.

245954C91

LAMP

ASSEMBLY - grain tank, see serviceable parts below, Refs. 28 - 31

1шт.

12

1317942C1

BRACKET

- grain tank lamp

1шт.

13

281-34912

SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"

SCREW - self-tapping, hex washer head, 3/8 NC x 3/4 inch, if used, grain tank lamp

1шт.

13

154273C1

BOLT,Hex Serr, 3/8" - 16 x 1", Spcl

- hex, self-locking, special, 3/8 NC x 1 inch, if used, grain tank lamp

1шт.

14

231-5146

FLANGE NUT,3/8"-16

Grain tank lamp Flg, USR, 3/8"-16

1шт.

245954C91

LAMP

ASSEMBLY - feeder, see serviceable parts below, Refs. 28 - 31

2шт.

18

561915R1

BRACKET

- lamp mounting, feeder

2шт.

19

154273C1

BOLT,Hex Serr, 3/8" - 16 x 1", Spcl

- hex, self-locking, special, 3/8 NC x 1 inchfeeder lamp

2шт.

20

231-5146

FLANGE NUT,3/8"-16

Feeder lamp Flg, USR, 3/8"-16

2шт.

245954C91

LAMP

ASSEMBLY - unloader, Includes: Ref. 28 - 31

1шт.

28

NSS

NOT SOLD SEPARAT

HOUSING - lamp (Order 245954C91)unloader

1шт.

29

A47179

BULB

LAMP - sealed beam (Replaces lamp A42294), unloader

1шт.

30

A25213

RETAINER

- shockproof, use with Hobbs lamp, unloader

1шт.

30

1252609C1

RETAINER

- shockproof, use with Midwest lamp, unloader

1шт.

31

530029R91

CONNECTOR, ELEC

CONNECTOR - lamp, unloader

1шт.

33

D37048

BUSHING

SEAT - lamp mounting (Replaces seat 1267358C2), unloader

1шт.

34

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, , Unloader lamp 1/2"

1шт.

35

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex, Unloader lamp 1/2"-13, G5

1шт.
