Запчасти Case IH 1670 (4-34) - FOUR WHEEL DRIVE AND LEVELING SYSTEM (06) - ELECTRICAL

1

1983642C1

HARNESS

- 4 wheel drive and leveling

1шт.

2

1983636C1

HARNESS

- 4 wheel drive and leveling

1шт.

3

1346049C1

VALVE

- rear brake, see figure 6-52 for rear wheel drive system

1шт.

4

1994687C1

VALVE

- 4 wheel drive, see figure 6-52 for rear wheel drive system

1шт.

6

1310827C2

SWITCH

- third gear lockout (Replaces switch 1310827C1)

1шт.

470-10620

SCREW,Pan HD, #6 - 32 x 1-1/4"

- machine, pan head slotted, No. 6 x 1-1/4 inch (Replaces screw 436670 )

2шт.

225-14106

NUT,#6-32

(Replaces nut 134530) #6-32

2шт.

138526

LOCK WASHER

- internal tooth lock, special, No. 6

2шт.

95-81108

WASHER,#6

- flat, 5/32 x 3/8 x 3/64 inch (Replaces washer 103337)

2шт.

7

1346051C1

VALVE

- leveling bypass, see figure 8-80 for hydraulic system

1шт.

8

1304243C91

VALVE

- selector, see figure 8-52 for hydraulic system

1шт.

9

1304695C1

CABLE

- high speed leveling

3шт.

12

1265622C2

SWITCH

- leveling limit

2шт.

1265634C1

ARM

- leveling switch

1шт.

440-11024

SCREW,Cross Pan Hd, #10-24 x 1 1/2"

- machine, pan head, No. 10-24 x 1 inch

2шт.

495-31016

WASHER,#6

2шт.

492-11010

LOCK WASHER,#10

WASHER, LOCK, #10

2шт.

225-14110

NUT,#10-24

2шт.

13

1304982C93

VALVE

ASSEMBLY - leveling, parts list figure 8-88

1шт.

14

1304228C92

BOX

ASSEMBLY - leveling control, parts list figure 4-68

1шт.

15

1346324C1

MOTOR

ASSEMBLY - hydrostatic, parts list figure 6-24

1шт.

16

1331338C1

SUPPORT

BAR - switch support

1шт.

17

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

- hex, 1/4 NC x 3/4 inch

2шт.

20

631760R91

ELECTRICAL WIRE

CABLE - leveling limit ground

2шт.

1304698C1

BAR

SUPPORT - switch

1шт.

173-210

SCREW,Sl Rnd Hd, #10 - 24 x 3/8"

- machine, round head slotted, No. 10 x 3/8 inch (Replaces screw 132830)

2шт.

21

1304693C1

CABLE

- header drive valve

2шт.

22

186057C1

SWITCH

- 4 wheel drive valve

1шт.

1310689C1

SWITCH

SUPPORT - switch

1шт.

23

196262C2

CABLE ASSY.

CABLE - leveling limit ground

1шт.

23

138842C1

CABLE

- reel speed solenoid ground

1шт.

24

109390

GROMMET,5/16" ID x 23/32" x .062", Diag Cut

- rubber, 5/16 x 23/32 x 7/16 inch

2шт.
