Заказать запчасти
Запчасти Case IH 1670 (5-12) - STEERING AXLE SHIELD (04) - STEERING
№
Артикул
Название
Примечание
Количество
1
1304655C1
SHIELD
- steering axle
1шт.
2
1304719C2
SUPPORT
- shield, left-hand
1шт.
3
1304720C2
SUPPORT
- shield, right-hand
1шт.
4
135270
SERRATED SCREW,5/16" - 18 x 3/4"
- slotted truss head, 5/16 NC x 3/4 inch, if used
2шт.
4
409-7516
BOLT,Hex Flg, 5/16" - 18 x 1", Spcl
If used Hex Flg, 5/16"-18 x 1", Serr
2шт.
5
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
1шт.
6
SERRATED SCREW,Truss HD, 3/8" - 16 x 3/4"
- slotted truss head, special, 3/8 NC x 3/4 inch
1шт.
7
231-5146
FLANGE NUT,3/8"-16
2шт.
8
1304561C1
SEAL
- tail box
2шт.
9
937875R1
SCREW,Serr, 1/4" - 20
- slotted truss head, 1/4 NC x 3/4 inch
10шт.
10
495-11028
WASHER,1/4", SAE
(flat, 9/32 x 5/8 x 1/16") 1/4", SAE
10шт.
14
1331285C1
SUPPORT ASSY.
SUPPORT - shield
1шт.
15
413-528
BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5
1шт.
17
495-11034
WASHER,5/16", SAE
5/16" SAE (flat, 11/32 x 11/16 x 1/16")
1шт.
18
425-105
NUT,5/16"-18, G5
- hex, 5/16 inch NC
1шт.
19
413-1228
BOLT,Hex, 3/4" - 10 x 1-3/4", Gr 5
- hex, 3/4 NC x 1-3/4 inch
2шт.
20
492-11075
LOCK WASHER,3/4"
3/4"
2шт.
25
1304744C1
SUPPORT
- shield
1шт.
26
38-1814
LOCK PIN,1/8" x 7/8", Slotted
Pin, 1/8" x 7/8", Slotted
1шт.
27
586591R1
COTTER PIN
PIN - hair, 1/8 inch
1шт.
28
135270
SERRATED SCREW,5/16" - 18 x 3/4"
- slotted truss head, 5/16 NC x 3/4 inch, if used
10шт.
28
409-7516
BOLT,Hex Flg, 5/16" - 18 x 1", Spcl
If used Hex Flg, 5/16"-18 x 1", Serr
10шт.
29
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
10шт.
30
203942C1
SPRING
- shield pivot
1шт.
37
1304657C1
BAR
STRIP - shield support
1шт.
38
186912C1
SUPPORT
- separator hood, left-hand
1шт.
39
186913C1
SUPPORT
- separator hood, right-hand
1шт.
40
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
- slotted truss head, 5/16 NC x 1/2 inch
4шт.
Выбрано товаров: 30
